Windows Virtual Desktop learning and readiness resources
Would you like to learn more about Windows Virtual Desktop? Consider watching these Ignite sessions: Scott Manchester's Mechanics Live (20 minutes) Windows Virtual Desktop Overview (43 minutes) Windows Virtual Desktop Deep Dive (56 minutes) A tour of Microsoft Windows Virtual Desktop (20 minutes) Office in Virtual Desktop environments (53 minutes) New multi-session virtualization capabilities in Windows (32 minutes) Register via http://aka.ms/wvdpreview to be notified for the public preview which will launch later this year.Deallocate VM on user logoff
Recently we've announced the public preview of start VM on connectwhich will allow your deallocated virtual machines getting started automatically when the assigned user tries to connect. Let us have a look how we can further optimize our cost by deallocating the VM when it is not used anymore. Let's first have a high level view on the needed steps: Create a custom role to deallocate a virtual machine Create a managed identity for your virtual machines Allow each virtual machine to deallocate itself via a role assignment implement logoff script and policies around idle/disconnected sessions So let's start by creating our custom role: Open the Azure portal, go toSubscriptionsand select the appropriate subscription Go toAccess control (IAM)and selectAdd a custom role. Next, name the custom role and add a description. In this example I'll call it"Deallocate VM on logoff" On thePermissionstab, add the following permission to the subscription you're assigning the role to: Microsoft.Compute/virtualMachines/deallocate/action When you're finished, selectOk. If you prefer a JSON definition, please use the following template: { "properties": { "roleName": "Deallocate VM on logoff", "description": "This custom role will allow your virtual machines to be deallocated when the user logs off.", "assignableScopes": [ "/subscriptions/<<<SubscriptionID>>>" ], "permissions": [ { "actions": [ "Microsoft.Compute/virtualMachines/deallocate/action" ], "notActions": [], "dataActions": [], "notDataActions": [] } ] } } After we've created our custom role, we'll need to create a managed identity for our virtual machines. By this managed identities we don't need to store any credentials locally on the virtual machine or in an Azure KeyVault and can assign each virtual machine granular permission to shutdown only itself. As this can be a bigger task, depending on the number of virtual machines you have in your personal host pools, I've prepared a script that will utilize the Azure PowerShell modules to assign that fine-grained permissions, so you may need to install those modules first: Install-Module -Name Az.Account,Az.Compute,Az.DesktopVirtualization,Az.Resources The script itself takes the host pool name, associated resource group and the role definition name selected above as parameters. It will then iterate through all virtual machines assigned to the specified host pool, create a managed identity when not already present and create a role assignment limited to the virtual machine itself: $hostPoolName = "<<<HostPoolName>>>" $resourceGroupName = "<<<ResourceGroupName>>>" $roleDefinitionName = "<<<RoleDefinitionName>>>" Connect-AzAccount $sessionHosts = Get-AzWvdSessionHost -HostPoolName $hostPoolName -ResourceGroupName $resourceGroupName foreach ($sessionHost in $sessionHosts) { <# get virtual machine by session host reference #> $resource = Get-AzResource -ResourceId $sessionHost.ResourceId $vm = Get-AzVM -ResourceGroupName $resource.ResourceGroupName -Name $resource.Name <# create system-assigned managed identiy unless it already exists #> $managedIdentity = ($vm.Identity | where Type -eq "SystemAssigned").PrincipalId if ($managedIdentity -eq $Null) { Update-AzVM -ResourceGroupName $vm.ResourceGroupName -VM $vm -IdentityType SystemAssigned $managedIdentity = ((Get-AzVM -ResourceGroupName $vm.ResourceGroupName -VMName $vm.Name).Identity | where Type -eq "SystemAssigned").PrincipalId } <# create role-assignment unless it already exists #> if ((Get-AzRoleAssignment -RoleDefinitionName $roleDefinitionName -ObjectId $managedIdentity) -eq $Null) { New-AzRoleAssignment -ObjectId $managedIdentity -RoleDefinitionName $roleDefinitionName -Scope $vm.Id } } Next we'll configure our session host to disconnect idle sessions and logoff disconnected sessions after a certain period of time: Connect remotely to the VM that you want to set the policy for. Open theGroup Policy Editor, then go toLocal Computer Policy>Computer Configuration>Administrative Templates>Windows Components>Remote Desktop Services>Remote Desktop Session Host>Session Time Limits. Find the policy that saysSet time limit for disconnected sessions, then change its value toEnabled. After you've enabled the policy, selectyour preferred time limit atEnd a disconnected session. Find the policy that says Set time limit for active but idle Remote Desktop Services sessions, then change its value to Enabled. After you've enabled the policy, select your preferred time limit at Idle session limit. The above settings also ensure that an user will get a warning message two minutes before reaching the specified time limit so he can press a key or move the mouse to prevent getting disconnected. In the last step we'll create the PowerShell script initiating the deallocation and configure it as a logoff script. The PowerShell script will query the details of your virtual machine using the Azure instance metadata, connect to Azure using the created managed identity and initiate the actual deallocation via REST API: $metadata = Invoke-RestMethod -Headers @{"Metadata"="true"} -Method GET -Proxy $Null -Uri "http://169.254.169.254/metadata/instance?api-version=2021-01-01" $authorizationToken = Invoke-RestMethod -Headers @{"Metadata"="true"} -Method Get -Proxy $Null -Uri "http://169.254.169.254/metadata/identity/oauth2/token?api-version=2021-01-01&resource=https://management.azure.com/" $subscriptionId = $metadata.compute.subscriptionId $resourceGroupName = $metadata.compute.resourceGroupName $vmName = $metadata.compute.name $accessToken = $authorizationToken.access_token $RestartEvents = Get-EventLog -LogName System -After (Get-Date).AddMinutes(-1) |? {($_.EventID -eq 1074) -and ($_.Message -match "restart" )} $SessionCount = (query user | Measure-Object | select Count).count - 1 # remove headline if (($SessionCount -gt 1) -or ($RestartEvents.count -ge 1)) { # skip deallocate because of user-sessions or initiated reboot } else { Invoke-WebRequest -UseBasicParsing -Headers @{ Authorization ="Bearer $accessToken"} -Method POST -Proxy $Null -Uri https://management.azure.com/subscriptions/$subscriptionId/resourceGroups/$resourceGroupName/providers/Microsoft.Compute/virtualMachines/$vmName/deallocate?api-version=2021-03-01 -ContentType "application/json" } To have that script executed upon logoff, we need to configure it: Connect remotely to the VM that you want to set the policy for. Open theGroup Policy Editor, then go toLocal Computer Policy>User Configuration>Windows Settings>Scripts (Logon/Logoff). Find the item that saysLogoff. Specify the script you've created on thePowerShell Scripts tab. When rolling out to bigger host-pools, ideally place the logoff script on a centrally accessible location, e.g. SYSVOL-share. Hope this short tutorial will help you take full benefit of the start VM on connect feature. Happy to read your feedback and comments below.Insider Preview: Single sign-on and passwordless authentication for Azure Virtual Desktop
Today we’re announcing the Insider preview for enabling an Azure AD-based single sign-on experience and support for passwordless authentication, using Windows Hello and security devices (like FIDO2 keys). With this preview, you can now: Enable a single sign-on experience to Azure AD-joined and Hybrid Azure AD-joined session hosts Use passwordless authentication to sign in to the host using Azure AD Use passwordless authentication inside the session Use third-party Identity Providers (IdP) that integrate with Azure AD to sign in to the host Getting started This new functionality is currently available in Insider builds of Windows 11 22H2, available in the Azure Gallery when deploying new session hosts in a host pool. Want a quick overview of the new functionality? Watch this intro video on Azure Academy! To get started with single sign-on, follow the instructions to Configure single sign-on which will guide you in enabling the new authentication protocol. To start using Windows Hello and FIDO2 keys inside the session, follow the instructions for In-session passwordless authentication to use the new WebAuthn redirection functionality. Learn more about the supported authentication methods supported by Azure Virtual Desktop, including single sign-on on our Identities and authentication page. Stay tuned for news about the upcoming public preview which will add support for Windows 10 and current Windows 11 hosts.(Azure) Virtual Desktop Optimization Tool now available
Optimizing images has always been an important component of preparing images as part of a traditional Remote Desktop Services (RDS) infrastructure or virtual desktop infrastructure (VDI). Optimizing session hosts, in particular, can increase user density and eventually lower costs. With the Virtual Desktop Optimization Tool, you can optimize your Windows 10, version 2004 multi- and single-session deployments in Windows Virtual Desktop. Note: The information in this post is community-driven; nothing has yet been officially launched by the Windows Virtual Desktop product team. Credit goes to Robert M. Smith and Tim Muessig from Microsoft, previously known as the VDIGuys, for creating this tool and make it available for free for the community. Windows 10 multi-session image name change As noted in recent announcements, Office 365 ProPlus is now Microsoft 365 apps for Enterprise. With this name change, we have updated the Windows Virtual Desktop image names in Azure Marketplace. As a result, when you are looking for an image in the Azure Marketplace image gallery, you should begin by selecting Windows 10 Enterprise multi-session, version 2004 + Microsoft 365 Apps – Gen1 as your baseline image. How the Virtual Desktop Optimization Tool works The (Windows) Virtual Desktop Optimization Tool disables services in the operating system that you most likely won’t need for your Windows Virtual Desktop session host. To make sure that your line-of-business (LOB) applications continue running as they should, there are some preliminary steps that should first performed. Note: There are settings default disabled when you run the scrip out of the box such as AppX Packages for the Windows Calculator. We strongly suggest analyzing the tool via the JSON files that include the default settings. This also gives you the opportunity to enable them before running the tool so they remain untouched. I'll explain more about this later on in the article. The full list of enhancements for native Windows services will be available soon. Bookmark Run and tune your Remote Desktop Services environment for the latest updates. Expected performance gains Windows Virtual Desktop value-added services provider and Microsoft partner LoginVSI performed early tests with the Virtual Desktop Optimization Too and gained over 100 users in their internal benchmarking lab environment with a Windows 10, version 2004 single session. We, therefore, assume that this gain will also be possible with Windows 10 Enterprise multi-session. VSImax asserts a maximum number of users that are able to log on to the virtual desktop hosts pool as part of the underlying infrastructure. That number is the "sweet spot" as going over that number will decrease performance for all users. (Thanks to LoginVSI for sharing these results with us.) Note: We recommend you use simulation tools to test your deployment using both stress tests and real-life usage simulations to ensure that your system is responsive and resilient enough to meet user needs Remember to vary the load size to avoid surprises. Desktops in the Cloud on Performance Optimizations for Windows Virtual Desktop with Robert and Tim (aka VDI Guys) We recently had the creators of the Virtual Desktop Optimization tool as guests on ourDesktops in the Cloudvideo-podcast. Robert and Tim explained everything you should know, as well as best practices and lessons learned. A must watch in extension to this article.Watch it below. How to use the Virtual Desktop Optimization Tool The Virtual Desktop Optimization Tool makes it possible to disable uncommon services for virtual desktop environments, such as Windows Virtual Desktop. Note: We recommend that you run the script after the Sysprep (System Preparation) process, most likely as startup script w with a large set of virtual machines. This is due to the AppX Packages that conflict and most likely the sysprep will fail. Download all scripts from the Virtual-Desktop-Optimization-Tool GitHub repository. Select Clone or download, followed by Download ZIP. Unzip the folder to your Windows Virtual Desktop session host(s) to a specified folder (e.g. C:\Optimize or C:\Temp). Note: You could also run the scripts as part of your image management procedure e.g. Azure image Builder (AIB) or Azure DevOps. Important information before running the tool There are settings default disabled when you run the scrip out of the box such as AppX Packages for the Windows Calculator. We strongly suggest analyzing the tool via the JSON files that include the default settings. This also gives you the opportunity to enable them before running the tool so they remain untouched. You can find the JSON file in the Windows built number folder, under ConfigurationFiles - e.g. C:\Optimize\2004\ConfigurationFiles. You've to put the settings to Enabled - that you want to keep as default. Below is the example file for AppX Packages, there are JSON files for Services and scheduled tasks as well. Another option is to remove the while entry out of the JSON file. AppxPackages.json - Example Windows Calculator App { "AppxPackage": "Microsoft.WindowsCalculator", "VDIState": "Enabled", "URL": "https://www.microsoft.com/en-us/p/windows-calculator/9wzdncrfhvn5", "Description": "Microsoft Calculator app" }, Services.json - example Windows Update Service { "Name": "UsoSvc", "VDIState": "Enabled", "Description": "Update Orchestrator service, manages Windows Updates. If stopped, your devices will not be able to download and install the latest updates." }, Prepare to launch Windows PowerShell and select Run as Administrator. In PowerShell, change the directory to the folder to which you downloaded the scripts, e.g. C:\Optimize or your own specific folder. Run the following command: Set-ExecutionPolicy -ExecutionPolicy Bypass Run the Virtual Desktop Optimization Tool using the following command: .\Win10_VirtualDesktop_Optimize.ps1 -WindowsVersion 2004 -Verbose Note: When you use a different version of Windows 10, you must change the WindowsVersion parameter. Version 1803 and later are supported for Windows 10 Enterprise. Windows 10 multi-session support is only available with Windows 10, version 2004 and later. Select Yes when prompted to reboot the session hosts(s). Start your Windows Virtual Desktop session. As you can see in the Task Manager comparison below, the number of threads and handles has decreased noticeably after running the Virtual Desktop Optimization Tool. Do you have any problems with orphaned Start Menu shortcuts after running the tool? Have the user open Task Manager, then end the following two processes: ShellExperienceHost.exe StartMenuExperienceHost.exe Have them check the Start Menu and they should be gone. Happy optimizing! 🙂 Let us know your feedback on the tool in the comment section below. Prefer to watch and learn? There’s also a video on Azure Academy available later this week by Dean Cefola. You can find it here.
Azure Virtual Desktop - Black Screens on logins - What we've tried so far
TLDR - Azure Virtual Desktop Black Screens. Could be 2 Min long, could be much longer. Tried removing stuck profiles, spun up all new VMs to see if that would fix it, finally disabled an application service that was polluting the Event logs constantly with appcrashes. Hoping that maybe the event logs weren't able to keep up so we had a black screen while events caught up. Grasping at straws. We started getting reports of black screens when users login to one of our AVD Host Pools. Our users are using FSLogix for profiles, but we've also seen the issue when logging via RDP with a local admin account. We tested and saw similar results where you login, FSLogix Prompt goes by, then to Preparing Windows, then black screen. In a normal login, this black screen will last 10-20 seconds before desktop comes available and user can begin their session. With this issue, we were seeing black screens that just stayed there until you forced a logout of your account. We saw some profile issues with the VMs in the pool appearing to be stuck on a VM when it should be removed upon logoff with FSLogix and we saw some stuck local_username FSLogix profiles still in the users folder. Instead of finding the needle in a haystack, we spun up a new group of VMs and put the others in drain mode / excluded. With the new VMs, logins from RD Client were working fine yesterday afternoon, evening and this AM. But later in the morning, we saw some issues with users getting a black screen lasting 90 sec - 2 min before desktop loaded in. I had it happen to me when logging in, but it seemed to go away once I tried a couple more times. I even directly RDPd into the host that I had the 2 min black screen for me and was able to get in quickly. So issue appears to still be showing, but not as bad. We looked in event logs and saw that one particular application - the Aspen Multicase Web service was polluting the service event logs with appcrash errors every few seconds. So we've disabled that application service on all the VMs in the pool and logins have been normal since. We read event logs that were event 4625 (failed login) but the event said event logs couldn't keep up and needed to stop duplicate events...so we were thinking that this service was constantly writing to event logs, could the slow logins happen when the service is trying to run, failing and writing to event logs. the logs wouldn't be able to write the login info. But every other change we made things seem fine afterward for a while, but then the black screen will come back for at least 90sec - 2 min. Any suggestions on things we can try / look at that could be causing this?Announcing public preview of Azure Virtual Desktop RDP Shortpath for public networks
Today I have the pleasure of announcing the public preview of RDP Shortpath for public networks. This Remote Desktop Protocol (RDP) feature establishes a direct UDP data flow between the Remote Desktop Client and Session host. RDP uses this data flow to deliver Remote Desktop and RemoteApp. Why does UDP matter? What is wrong with using TCP? Reliability First of all, TCP is an unreliable transport for long-living user sessions. That is right, let me repeat – TCP is unreliable. If you know networking, you might think I'm crazy saying that. But trust me, it's true. TCP is an excellent protocol for guaranteed delivery of small amounts of data. It's easy to implement. Applications like browsers or email clients just send the data and forget about it. They don't need to implement the logic to verify that data is delivered or is delivered in time and with no errors. The protocol will ensure the packet consistency; order, and retry the transmission if delivery fails. However, RDP uses long running connections and long-running TCP connections are problematic. Let me explain this. When Remote Desktop Client establishes the reverse connect session, it consists of two TCP connections, one from the client to the gateway and another from the session host to the same gateway. It looks straightforward, but let's check what is going on over the wire. Let's take the connection from the session host to a gateway as an example. First, Remote Desktop Service opens a local TCP socket on the local network interface. Then, it sends a TCP SYN to the gateway. What happens with the packet? The packet goes out of the Virtual Machine NIC. Then, it travels over the Azure Virtual Network, reaching the NAT gateway, Load Balancer, Azure Firewall, or other NVA. All those virtual elements perform either connection tracking or network address translation, which means that virtual appliances track the status of the TCP connection in memory. Then, after the NAT, the TCP packet travels over the Azure backbone to the Azure Virtual Desktop Gateway. The gateway is not a single big VM. Instead, it is a distributed cluster of applications running on Azure App Service. On the backend, multiple load balancers and firewalls are tracking the TCP session and translating the packet again to the private IP address and port of the App Service instance. And believe me, this is a simplified description. Software-Defined networks perform a lot more translations and packet encapsulations while tracking the state of the connections. On the client side, a similar story. First, the packet is sent to the home router that performs the translation on the client. Then it may pass the packet inspection firewall. At some point, the packet will reach the AVD gateway and pass through those load balancers again. Microsoft is doing a lot to improve the reliability of the Azure part of the path your TCP packet takes, including fault-tolerant load balancers and scalable NAT gateways. However, not all components are in our control. For example, customers deploy force tunneling on-premises, Zero Trust Network services, and use deep packet inspection. This is complicated even more by dynamic routing, VPNs, and software-defined networking setups. Any one of those dozens of physical or virtual appliances on the way of RDP flow may fail or may need to be serviced. In such cases, the TCP session could be dropped. However, such network failures always would come as a surprise. This is because the TCP protocol stack will never report any network errors to the application on the higher level until it reaches the point where the connection is not recoverable. We take this seriously at Azure Virtual Desktop. We have proactive monitoring of the session and a fast reconnect for TCP-based transport. However, even if the sessions are automatically re-established, it takes some time and affects the user experience. The solution comes with using UDP-based transport. First, the tracking of UDP streams is done differently on the load balancers, firewalls, and NAT devices. Second, because of the connectionless nature of UDP, those network devices cannot reset the UDP flow by sending the RST signal. Each packet in the UDP stream is independent of each other and could be lost without affecting the health of the entire flow. Third, UDP is more tolerant to the temporary network interruptions caused by wireless interference or by changes in dynamic routing. UDP does not care about each individual packet's packet order or delivery. It does not have built-in congestion or rate control, which means that if you want to use UDP, you need to implement all of this on your own. And that is what we did by implementing URCP for RDP Shortpath. With this setup, we have better visibility into the network. We see delays in every packet we send and immediately recognize if some data was lost in transit. However, we resend it only if we need to do that. Bandwidth TCP is great for local networks but not on the Internet. Yes, if the packet is lost, it will be retransmitted, but that's not the worst thing that could happen. Bandwidth availability is an essential factor. Unfortunately, TCP congestion control algorithms limit the ability to saturate the network. It is also highly inefficient in window scaling, especially on high latency networks. Knowing the network better and not being protected by TCP algorithms, we can signal back to the RDP stack. This will adjust the encoding parameters or change the frame rate of the graphics stream. This is not news for those who manage VoIP or real-time communications like Teams. Most of those applications use UDP as the primary transfer. Not just graphics is improved by UDP. Your file transfers, print jobs, MMR, and device redirection take advantage of increased bandwidth and reduced latency. In addition, you can now use VoIP applications on your remote desktops even if they have no specific optimizations for VDI environments. Latency So UDP is suitable for RDP, but is UDP enough? Customers implement UDP-based gateways in many on-premises deployments and other virtualization products. Is it good? It's easy to implement. But in the case of the multitenant cloud service like Azure Virtual Desktop, it would require the inbound firewall rules to be configured, which is unacceptable by most customers. On top of that, such a gateway is just another address translation device that acts as a performance bottleneck and reduces the available bandwidth. It also requires packet travel for the gateway location and increases the network latency. Solution We understand the challenges of remote protocols in the cloud. Because of that, when we developed RDP Shortpath, we focused not just on enabling UDP for your user sessions but also on enabling it most efficiently. For this, we focused on establishing a direct UDP flow between client and session host, bypassing all unnecessary gateways. Many of you are familiar with RDP Shortpath for managed networks. IT works great for many customers, with users accessing their remote desktops from the enterprise and office settings. However, the feedback that we hear from you clearly shows that while RDP Shortpath is great for managed networks such as ExpressRoute, it is a non-starter for users who travel or work from their homes. We recognize these challenges, and our protocol team worked hard on the feature released to the public preview today. Meet RDP Shortpath for public networks. Like its oldest brother, this feature establishes direct UDP flow for RDP. However, it does not require any inbound ports to be opened on the firewall. Instead, it will automatically select the network conditions. It uses a combination of NAT traversal protocols such as STUN and UPnP and the process of Interactive Connectivity Establishment (ICE). RDP then would establish the direct UDP flow in most network setups. As a result, your users would get lower latency, better network utilization, and high tolerance to packet loss or network configuration changes. To demonstrate the benefits of RDP Shortpath, I recorded a video that shows the commercial for Microsoft Flight Simulator. I watched the video over two RDP sessions. One with reverse connects TCP transport, another with RDP Shortpath. To keep the setup closer to reality, I used WAN emulator software to introduce a packet loss. For reference, I added the original video to the bottom of the screen. As you can see, UDP, even with a horrible 10% packet loss, gives you smoother playback and better image quality. How does RDP Shortpath work? RDP Shortpath for public networks performs dynamic analysis of your network. It works in many cases, but some configurations are not compatible. For sure, you must have the UDP traffic flowing on your network. But even if UDP is allowed on the network, RDP Shortpath may fail if you use double NAT setups. This includes a Carrier-Grade NAT used by some cellular operators. It also may fail because some firewalls specifically block NAT traversal protocols or are configured to prevent port reuse. In such cases, you may increase the chance of establishing the Shortpath connection by enabling the native IPv6 or using Teredo networking. You may also use Azure load balancer for the outbound network access or assign a public IP address to a VM. There's no need to allow any inbound connectivity in all these cases. No need to open port 3389 or any other port. If RDP Shortpath fails to establish, the user wouldn't notice a thing and will continue to use the TCP -based reverse connection transport. Getting started with RDP Shortpath for public networks You can find information about RDP Shortpath configuration in Azure Virtual Desktop documentation. It also includes recommendations for troubleshooting. Thanks This release results from the work of multiple teams at Microsoft, and I would like to thank all my colleagues for their outstanding work. I am also grateful to all customers and MVPs that participated in the private previews and provided their feedback.
ARM AVD with Terraform
Deploying Azure Virtual Desktop with Terraform This article has been written in collaboration with my colleaguesJensheerin,Stefan GeorgievandJulie NG. Terraform is a tool that enables you to completely automate infrastructure builds through configuration files. It provides versioning for configurations, which makes it easy to deploy and maintain your existing Azure Virtual Desktop deployments on Microsoft Azure. This article provides an overview of how to use Terraform to deploy a simple Azure Virtual Desktop environment. This is to deploy ARM AVD, not AVD Classic. There are several pre-requisites required to deploy Azure Virtual Desktop, which we will assume are already in place. Ensure that you meet the requirements for Azure Virtual Desktop Terraform must be installed and configured as outlined here. If you are completely new to Azure Virtual Desktop, please check them out here: What is Azure Virtual Desktop? - Azure | Microsoft Docs There are several topics that should be considered when creating a production Azure Virtual Desktop environment, that we haven’t been able to include in the scope of this article, such as security, monitoring, BCDR and image build. This article aims to get you started with building a PoC for Azure Virtual Desktop via Terraform. All the code in this article can be found in the repo: RDS-Templates/wvd-sh/terraform-azurerm-azuresvirtualdesktop at master · Azure/RDS-Templates (github.com) Note: Terraform is an open source tool hosted in GitHub. As such, it is published "as is" with no implied support from Microsoft or any other organization. However, we would like to welcome you to open issues using GitHub issues to collaborate toward future improvements to the tool. AVD Components To deploy AVD we will need to understand what components are required. We’re assuming that your pre-requisites are already in place. Active Directory - in this worked example, we are using ‘on-prem’ AD running on DCs in a separate VNet. The code could easily be modified to use AADDS though. Users in AAD that will be given access to AVD A VM Image (or you can use a marketplace image) Components we will deploy in this article Virtual Desktop Environment Networking Infrastructure Session Hosts Profile Storage Role Based Access Control Our architecture should look like the below once completed (sections in white are pre-reqs, grey will be deployed). Setting up Terraform You’ll need to authenticate to Azure to run the templates – the steps to do that are here: If you want to use Visual Studio Code please have a look at this article. Once your environment is ready, we can start to understand how to deploy all of the required resources. 1. AVD environment First up we will deploy the environment for Azure Virtual Desktop. In this section we will deploy the following resources: Resource Group Workspace Hostpool Hostpool registration expiration date (create a time_rotating resource) Application Group (our DAG) Application Group association to workspace Before we create templates for the resources we need to configure the Azure Provider. To do this we will create a providers.tf file and add the following: terraform { required_providers { azurerm = { source = "hashicorp/azurerm" version = ""~>2.0"" } } } provider "azurerm" { features {} } The full code for provider.tf can be found here. The Terraform documentation for AVD is here: azurerm_virtual_desktop_workspace | Resources | hashicorp/azurerm | Terraform Registry Then to create the resources, first create main.tf and start adding resources in the format: resource "azurerm_virtual_desktop_workspace" "workspace" { name = var.workspace location = var.deploy_location resource_group_name = azurerm_resource_group.rg.name friendly_name = "${var.prefix} Workspace" description = "${var.prefix} Workspace" } Note that there are several dependencies in the order that resources are created. We can specify those using the following depends_on = [azurerm_virtual_desktop_host_pool.hostpool,azurerm_virtual_desktop_workspace.workspace] In this case we are specifying the dependency for provisioning the Desktop Application group – that the hostpool and workspace must already exist before we try to create this resource. We have also referenced some variables in here, so let’s create a variables.tf file for those now and add our variables. They will be in the following form: variable "deploy_location" { type = string default = "West Europe" description = "location" } We will also need to add variables for: Resource group name Prefix (this will be appended to resources such as session hosts) Host pool name A full list of the variables that are referenced are listed at the end of the article in step 7. We can deploy at this point and it will create the basic AVD components, but no session hosts. To add the session hosts, we need to ensure we can access Active Directory. For this example we are assuming that we are using AD rather than AADDS. We are also assuming you have a domain controller in an Azure VNet. 2. Networking infrastructure We will create a new VNet for our session hosts and peer it to our AD VNet. we’ve also included an NSG here with a sample rule – I’d strongly suggest modifying them to meet your own security requirements. Components we will deploy here: Session Host Virtual Network Session Host Subnet NSG NSG – Subnet association VNet Peering to Active Directory VNet The full template can be found in networking.tf The new concept we have here is using data to retrieve the properties of our existing Active Directory (Hub) VNet. We can then pass the ID to new peering we are creating. data "azurerm_virtual_network" "ad_vnet_data" { name = var.ad_vnet resource_group_name = var.ad_rg } resource "azurerm_virtual_network_peering" "peer1" { name = "peer_avd_ad" resource_group_name = azurerm_resource_group.rg.name virtual_network_name = azurerm_virtual_network.vnet.name remote_virtual_network_id = data.azurerm_virtual_network. ad_vnet_data.id } resource "azurerm_virtual_network_peering" "peer2" { name = "peer_avd_ad" resource_group_name = var.ad_rg virtual_network_name = var.ad_vnet remote_virtual_network_id = azurerm_virtual_network.vnet.id } Again, we can see that we have referenced several variables, so you’ll need to add the following to your variables.tf file: ad_vnet – the name of the VNet containing our Domain Controllers ad_rg - resource group containing DCs dns_servers – custom DNS servers that we’re using for our new VNet vnet_range – Address range for our new VNet subnet_range - Address range for our new subnet Now we should have all our basic infrastructure in place, we can move onto the session hosts. 3. Session Hosts Here we are deploying and configuring our session hosts. In this example, we will create a new Terraform config file, host.tf to do this. Full code is here. We will also add our variables to the variables.tf file. Components to deploy in this section: NIC for each session host Session Host VM(s) Domain-join VM extension Dsc VM extension to register session host Random strong for local vm password Local variable for registration token This part is slightly more complex than the infrastructure deployment. The new concepts in this section are covered below. We firstly need to create a local variable for our registration_info token to allow us to register the VM to the host pool. This is later passed as a protected setting to the dsc extension resource. locals { registration_token = azurerm_virtual_desktop_host_pool.hostpool.registration_info[0].token } We’re also creating a random local password – which needs to meet the AVD requirements: resource "random_string" "avd_local_password" { count = "${var.rdsh_count}" length = 16 special = true min_special = 2 override_special = "*!@#?" } In the password section you will see us referencing rdshcount. This allows us to deploy a variable number of VMs to our host pool. Using this counter will be used for the VM, the NICs, local passwords and the extensions. We are also using the count meta-argument to refer to specific instances: resource "azurerm_windows_virtual_machine" "avd_vm" { count = "${var.rdsh_count}" name = "${var.prefix}-${count.index + 1}" resource_group_name = var.rg_name location = var.deploy_location size = var.vm_size network_interface_ids = ["${azurerm_network_interface.AVD_vm_nic.*.id[count.index]}"] provision_vm_agent = true admin_username = "${var.local_admin_username}" admin_password = "${random_string.AVD-local-password.*.result[count.index]}" os_disk { name = "${lower(var.prefix)}-${count.index +1}" caching = "ReadWrite" storage_account_type = "Standard_LRS" } source_image_reference { publisher = "MicrosoftWindowsDesktop" offer = "Windows-10" sku = "20h2-evd" version = "latest" } depends_on = [azurerm_resource_group.rg, azurerm_network_interface.AVD_vm_nic] } The VM resource is also where we specific the source image for the build. If you need a different market place image you can get the image SKU details using: Get-AzVMImageSku -Location <location> -PublisherName MicrosoftWindowsDesktop -Offer windows-10 (or -Offer office-365 if you want the image including M365 apps). Deploying a custom image with the shared image gallery is a topic for a follow up article. The additional variables we need to specify now are: rdsh_count domain_name domain_user_upn domain_password vm_size ou_path local_admin_username 4. Profile Storage For this example we’ll deploy our profile storage using Azure Files. Step 6 has the steps to configure NetApp Files if you prefer this option. To do this we’ll need to deploy the following resources: A dedicated resource group for our Storage account Azure File Storage account Azure Storage Share Assign AAD group to the Storage (Storage File Data SMB Share Contributor) We will deploy a new resource group. We are using a random string to generate a globally unique name for our Storage account. We are creating a file called afstorage.tf for this (and the full code is included here). We are appending a random string to the storage account name to ensure uniqueness – as such we also use the output command so that we can see the name of our new storage account. We can use the outputs.tf file to define our outputs. output "storage_account_name" { value = azurerm_storage_account.storage.name } Further configuration will be needed to enable AD authentication if you choose that direction and to configure NTFS permissions of SMB 5. RBAC Now that we have all our infrastructure deployed, let us give our users access. Again, we will create a new config file for this – rbac.tf. This can also be modified to assign users to custom roles, or to the other desktop virtualization roles that are already built in: Built-in roles Azure Virtual Desktop - Azure | Microsoft Docs The components we’re creating here are: Azure Active Directory Group AAD group member AAD role assignment Before we start, we’ll need to add the azuread provider to our list of required providers in our provider.tf as we need to use this for some of the AAD resources. terraform { required_providers { azurerm = { source = "hashicorp/azurerm" version = "~>2.0" } azuread = { source = "hashicorp/azuread" } } } To assign the RBAC permissions we need to pass a list of existing AAD Users and then add these to a new AAD group that we are creating. We will use the AzureAD_user and azurerm_role_definition datasources to retrieve information about our users and the role we’re assigning (in this case the builtin Desktop Virtualization user). data "azuread_user" "aad_user" { for_each = toset(var.avd_users) user_principal_name = format("%s", each.key) } data "azurerm_role_definition" "role_def" { name = "Desktop Virtualization User" } We’re also going to use for_each to loop through that list of users (both when getting the UPN from AAD and when adding to the group). resource "azuread_group_member" "aad_group_member" { for_each = data.azuread_user.aad_user group_object_id = azuread_group.aad_group.id member_object_id = each.value["id"] } Lastly we’ll scope the role assignment to the application group we created at the start and apply it to the group containing our users. resource "azurerm_role_assignment" "role" { scope = azurerm_virtual_desktop_application_group.dag.id role_definition_id = data.azurerm_role_definition.role_def.id principal_id = azuread_group.aad_group.id } We also need to add the 2 new variables: aad_group_name avd_users avd_users will be an array to allow us to pass multiple users. Up to now we have either specified default values for our variables or will pass them during deployment. To make things simpler we will create an env.tfvars file to pass our environment specific variables. You can add as many (or few) pre-configured variables here, but keep security in mind if you are putting confidential data in there. A sample might look like: deploy_location = "west europe" rg_name = "avd-resources-rg" vnet_range = ["10.1.0.0/16"] subnet_range = ["10.1.0.0/24"] prefix = "avd" avd_users = [ "user1@<domain>.com", "user2@<domain>.com" ] dns_servers = ["10.0.0.4", "168.63.129.16"] 6. NetApp Storage As an alternate to Azure Files you also have the option to deploy NetApp Storage for Azure Virtual Desktop profiles. To use NetApp Files you need to request access Register for Azure NetApp Files | Microsoft Docs. To deploy the storage we’ll need to deploy the following resources: A dedicated subnet for NetApp NetApp storage Account NetApp storage Pool NetApp storage Volume For simplicity we’ll deploy our subnet to the same Vnet we created earlier, and will use the same resource group and location variables. You may want separate resource groups and/or more complex networking in a production deployment. We are creating a file called netappstorage.tf for this and the full code can be found in the folder options/netapp. We also need to add some new variables (and you’ll probably want to update the default values as well): NetApp_acct_name NetApp_pool_name NetApp_volume_name NetApp_smb_name NetApp_volume_path NetApp_subnet_name NetApp_Address Now we should have created 9 Files: Main.tf Networking.tf Host.tf afstorage.tf (or netappstorage.tf) Rbac.tf Variables.tf defaults.tfvars Outputs.tf Providers.tf 7. Variables All of the variables that we have referenced so far are described here (they are also in variables.tf) Name Description Default rg_name Name of the Resource Group in which to deploy these resources AVD-TF deploy_location West Europe hostpool Name of the Azure Virtual Desktop host pool AVD-TF-HP ad_vnet Name of domain controller VNet - dns_servers Custom DNS configuration - vnet_range Address range for deployment VNet - subnet_range Address range for session host subnet - avd_users The resource group for AD VM [] aad_group_name Azure Active Directory Group for AVD users - rdsh_count Number of AVD machines to deploy 2 prefix Prefix of the name of the AVD machine(s) - domain_name Name of the domain to join - domain_user_upn Username for domain join (do not include domain name as this is appended - domain_password Password of the user to authenticate with the domain - vm_size Size of the machine to deploy Standard_DS2_v2 ou_path The ou path for AD "" local_admin_username The local admin username for the VM - netapp_acct_name The NetApp account name AVD_NetApp netapp_pool_name The NetApp pool name AVD_NetApp_pool netappvolumename The NetApp volume name AVD_NetApp_volume netapp_smb_name The NetApp smb name AVDNetApp netapp_volume_path The NetApp volume path AVDNetAppVolume netapp_subnet_name The NetApp subnet name NetAppSubnet netapp_address The Address range for NetApp Subnet - Note: Variables in italic are optional and only needed if you are deploying NetApp Files, these are included only in the variables template in the netapp folder. 8. Deploy! The templates can be downloaded from github if you now want to deploy this yourself. There are also some additional configuration files for other functionality that we hope to cover in further articles soon. Once Terraform is setup and you have created your Terraform templates, the first step is to initialize Terraform. This step ensures that Terraform has all the prerequisites to build your template in Azure. terraform init The next step is to have Terraform review and validate the template. This step compares the requested resources to the state information saved by Terraform and then outputs the planned execution. The Azure resources aren't created at this point. An execution plan is generated and stored in the file specified by the -out parameter. We also need to pass our variable definitions file during the plan. We can either load it automatically by renaming env.tfvars as terraform.tfvars OR env.auto.tfvars. We then use the following to create the execution plan: terraform plan -out terraform_azure.tfplan If you don’t rename your variable file, use: terraform plan -var-file defaults.tfvars -out terraform_azure.tfplan Note:When you're ready to build the infrastructure in Azure, apply the execution plan - this will deploy the resources: terraform apply terraform_azure.tfplan If you update the templates after you have deployed, you will need to rerun the plan and apply steps for them to reflect in Azure. Troubleshooting Terraform deployment Terraform deployment can fail in three main categories: Issues with Terraform code Issues with Desired State Configuration (DSC) Conflict with existing resources Issues with Terraform code While it is rare to have issues with the Terraform code it is still possible, however most often errors are due to bad input in variables.tf. If there are errors in the Terraform code, please file a GitHub issue. If there are warning in the Terraform code feel free to ignore or address for your own instance of that code. Using Terraform error messages it's a good starting point towards identifying issues with input variables Issues with DSC To troubleshoot this type of issue, navigate to the Azure portal and if needed reset the password on the VM that failed DSC. Once you are able to log in to the VM review the log files following the guidance here: Troubleshooting DSC - PowerShell | Microsoft Docs Conflict with Existing resources If you have previously deployed resources with the same name, you may see a deployment failure. Deployment will stop if any failures occur. You can use: Terraform destroy To clean up resources that were created by the Terraform Apply command. You can pass it the same options as the apply command. The destroy command may fail trying to delete the subnet if associated resources have not been deleted first. In this case you may need to manually delete resources associated with the subnet before running destroy, or you can delete the whole resource group manually. 9. Final Configuration You’ll notice we didn’t configure the session hosts to use our profile storage at any point. There is an assumption that we are using GPO to manage FSLogix across our host pools as documented here: Use FSLogix Group Policy Template Files - FSLogix | Microsoft Docs. At a minimum you’ll need to configure the registry keys to enable FSLogix and configure the VHD Location to the NetApp Share URI: Profile Container registry configuration settings - FSLogix | Microsoft Docs If not using GPO, the registry keys could be manually added as part of the build to the session host. Please comment below if you have any questions or feedback!Start VM on connect starts Public Preview!
For all early birds who want to start testing, keep in mind that we have the following limitations: You can configure the setting on validation pool only (we will update this post when you can enable on non-validation too) You can apply this setting for personal host pools only. You can access this setting from PowerShell and RestAPI only. Please review carefully the additional pre-requisites and set-up guidance here in our documentation. We are working to make the setting available for you through the Azure portal. Later in preview you can expect support for pooled hostpools and support for remaining Remote Desktop clients. We will keep you updated in this forum. Please share your feedback by commenting to this post or create a new post.MSIX app attach Azure portal integration public preview
MSIX app attach is an application layering solution that allows you to dynamically attach an application (that is an MSIX package) to a user session. Separating the application from the operating system makes it easier to create a golden virtual machine image, and you get more control with providing the right application for the right user. Previously, you had to use PowerShell scripts to enable MSIX app attach. MSIX app attach capability is now available in public preview in the Azure portal and is integrated with Azure Resource Manager. This eliminates the need for custom scripts and makes it possible to publish your packaged applications to application groups with a few clicks. Draft troubleshooting guide for MSIX app attach is available here. Overview and requirements Before you get started, make sure to fill out and submitthis formto enable MSIX app attach in your subscription. If you don't have an approved request, MSIX app attach won't work. Approval of requests can take up to 24 hours during business days. You'll get an email when your request has been accepted and completed. The following are the requirements to setup MSIX app attach in a Windows Virtual Desktop environment: Host pool in Windows Virtual Desktop with at least one active session host Host pool in the validation environment MSIX packaged application expanded into an MSIX image MSIX image is uploaded to file share The file share is accessible for all session hosts in the host pool When using a digital certificate that is not sourced from a CA please follow instructions hereon each VM in the host pool This video walks through the MSIX app attach UI. Deploy WVD (Windows Virtual Desktop) host pool The steps for deploying a WVD host pool are outlined here. It is mandatory to provision the session host pool in the validation environment. MSIX application MSIX app attach requires an application packaged as MSIX. If you do not have an MSIX application you can use the MSIX Packaging tool to repackage a Win32 application to MISX application. Instructions are available here. Prepare MSIX image MSIX app attach needs MSIX application to be stored in a VHD(x). Steps on how to perform the expansion are available here. If you do not have access to an MSIX application and MSIX images feel free to use these. They are provided without any guarantees and should not be used in production environments: Application name URL Chrome as MSIX image https://1drv.ms/u/s!Amut9BnVnw7mkOVMWy-sU8aiaStuxQ?e=AqwZ0D Chrome in an MSIX package https://1drv.ms/u/s!Amut9BnVnw7mkOVLPExhghP4iM8LRQ?e=wJHd9P Microsoft Edge Dev v89 as MSIX image https://1drv.ms/u/s!Amut9BnVnw7mkOVddlHiIoei4RdROQ?e=kwdvDq Microsoft Edge Dev v89 as MSIX package https://1drv.ms/u/s!Amut9BnVnw7mkOVczWWmEiUhv2IC3A?e=eBGL8B Microsoft Edge Dev v87 as MSIX image https://1drv.ms/u/s!Amut9BnVnw7mkOVbdz4gmTb7rqHoeg?e=6dEhj5 Microsoft Edge Dev v87 as MSIX image https://1drv.ms/u/s!Amut9BnVnw7mkOVaArIPkiAg5XzusQ?e=ZthNbz PowerBI as MSIX image https://1drv.ms/u/s!Amut9BnVnw7mkOVkUdswoKXTk9dfUw?e=fGTHy5 Note: this has dependencies that need to be delivered in the master image Links available here https://1drv.ms/u/s!Amut9BnVnw7mkOQth1hkT-SRdP2__g?e=YHbice PowerBI as MSIX package https://1drv.ms/u/s!Amut9BnVnw7mkOVi5SXqDxAr6MBAKw?e=pm1c2q WVDMigration as MSIX image (test different cert type) https://1drv.ms/u/s!Amut9BnVnw7mkOIEPLX6PYOzx96nrg?e=9qEpJc WVDMigrationBAD as MSIX image (bad packaging format) https://1drv.ms/u/s!Amut9BnVnw7mkOF6izJaA6rMxih_fQ?e=VU6Wbp Microsoft Edge Dev v87 as MSIX image (expired cert) https://1drv.ms/u/s!Amut9BnVnw7mkOJamDr-mrs3rOoeCg?e=43JT7E Notepad++ as MSIX image (missing cert test) https://1drv.ms/u/s!Amut9BnVnw7mkOF-o-E-bhp_btLgJw?e=6DO9ea If you are using your own application, you will need to install the certificate used to sign the MSIX package. Install certificates If you are using the provided MSIX applications, there are two certs: For Chome, Edge, and Power Bi: WVDContosoAppAttach. For WVDMigration*, WVDMigrationFabrikam Configure a file share All session hosts need access to the file share with MSIX app attach packages. This Tech Community blog covers the process. Configure MSIX app attach via Azure portal Open a browser, preferably in incognito mode, and load the following link: https://preview.portal.azure.com/?feature.msixapplications=true#home In the search bar type Windows Virtual Desktop and click on the service. Select a host pool where MSIX applications are to be delivered. Select MSIX packages. This will open the data grid with all MSIX packages currently added to the host pool. Click + Add. This will open the Add MSIX package blade. MSIX image path – this is UNC path pointing to the MSIX image on the file share. For example, \\storageaccount.file.core.windows.net\msixshare\appfolder\MSIXimage.vhd. MSIX package – if a valid, resolvable, and accessible path is provided this drop-down will be populated by all the MSIX packages in the MSIX image. Package applications – list of MSIX applications available in an MSIX package. Display name – Optional display name to be presented in the interface. Version – MSIX package version automatically delivered from parsing the package. Registration type On-demand – this is the recommended type of registration. It postpones the full registration of the MSIX application until and the user starts the application. Log on blocking – this type of registration is executing during session logon hence adding time to session logon completion. State – MSIX package has two states (Active and Inactive). When a package is active users can interact with it. Inactive packages are ignored by WVD and not delivered to users. Click Save. Publish MSIX application to an application group In the WVD resource provider navigate to the Application groups blade. Select an application group. Note: DuringMSIX app attach preview MSIX app attach remote apps may disappear from the user feed. The remote MSIX apps can disappear from the user feed because host pools in the evaluation environment may get served by an RD Broker in a production environment (this happens when the RD broker optimizes to improve the end-user experience). Because the RD Broker in the production environment doesn't understand the date of the MSIX app attach remote apps, it won't display them. Select the Applications blade. The Applications grid will display all currently added applications. Click + Add to open the Add application blade. Application source For desktop app groups the only source for applications is anMSIX package. For remote app group, there are three sources of applications. Start menu App path MSIX package MSIX package – display list of packages added to the host pool. Display name – Optional display name to be presented in the Applications interface. Description – Short description. Note the options below are only applicable to remote application groups. Icon path Icon index Show in web feed Click Save. Assign users to app group Select app group. Select Assignments To assign individual users or user groups to the app group, select +Add Azure AD users or user groups. Select the users you want to have access to the apps. You can select single or multiple users and user groups. Select Save. It will take five minutes before the user can access the application. Change MSIX package state Via the Applications grid Select MSIX packages. This will open the data grid with all MSIX packages currently added to the host pool. Select one or multiple that need to have their state change and click the Change state button. Via update package Select MSIX packages. This will open the data grid with all MSIX packages currently added to the host pool. Click on Package name in the MSIX packages grid this will open the blade to update the package. Toggle the State via the Inactive/Active button as desired and click Save. Change MSIX package registration type Select MSIX packages. This will open the data grid with all MSIX packages currently added to the host pool. Click on Package name in the MSIX packages grid this will open the blade to update the package. Toggle the Registration type via the On-demand/Log on blocking button as desired and click Save. Remove MSIX package Select MSIX packages. This will open the data grid with all MSIX packages currently added to the host pool. Select one or multiple that need to be removed click the Remove button. Removing MSIX application Navigate to the host pool and select Application groups. Select the application group from which the MSIX application is to be removed. From the application group blade select Applications. Select the desired application and click Remove.Announcing new management, security, and monitoring capabilities in Windows Virtual Desktop
With the global pandemic, we are seeing increasing demand for technologies that enable remote work. We’ve seen significant growth in the use of Windows Virtual Desktop, as organizations use it to ensure that their employees have access to the desktops and tools they need to stay productive. To help customers continue to accelerate this move to secure remote work with Windows Virtual Desktop, we are announcing several new capabilities that make it even easier to deploy, secure, and scale your virtual desktop deployments. These new capabilities will be available in public preview by the end of the calendar year 2020. Before we dive into the new capabilities, we want to take a moment to share some of the experiences of our customers. Sebastian Meyer, the Global Service Owner for Modern Client Technologies at Beiersdorf Shared Services, shared his thoughts in moving to Windows Virtual Desktop to modernize his virtual desktop infrastructure. "What Microsoft has developed here is simply phenomenal! Windows Virtual Desktop serves so many use cases and is very close to the end user. We were able to achieve maximum success with the project." You can read the full story here. Internally here at Microsoft, we are of course facing the same challenges as many of you. For example, getting a corporate laptop in the hands of new employees and interns takes time and impacts productivity. Windows Virtual Desktop is helping our new hires by providing a secure and productive remote work experience with access to the apps they need to get working immediately: “Windows Virtual Desktop allows you to create virtual desktops that work just like a physical Windows PC would,” says Mark Lawrence, a senior program manager on Microsoft’s digital security team. “That means the people who use one—new hires, interns, and so on—get access to the Windows Start menu, with Microsoft’s productivity applications, the Microsoft Edge browser, and everything else they would need to work at any location. No more waiting for a physical device delivery.” You can read the full story here. Simplified Management With Windows Virtual Desktop, you can move from a simple proof-of-concept (PoC) to a fully operational environment faster than ever before. As you start to scale your deployment, here are some new capabilities that will help you manage and operate your deployment efficiently. Microsoft Endpoint Manager integration Microsoft Endpoint Manager allows you to manage policies and distribute applications across devices. You can now enroll Windows Virtual Desktop virtual machines that are hybrid Azure Active Directory domain-joined (joined to your on-premises Active Directory and registered with your Azure Active Directory) with Microsoft Intune and manage them in the Microsoft Endpoint Manager admin center the same way as physical devices. This simplifies management, provides a centralized view across both physical devices and virtual desktops, and creates new areas of collaboration. The Microsoft Endpoint Manager integration is generally available for Windows 10 Enterprise desktops - you can learn more in the public FAQ. The public preview for Windows 10 Enterprise multi-session will be available in the coming months and will initially support policies at the device level. MSIX app attach in Azure portal MSIX app attach is an application layering solution that allows you to dynamically attach an application (that is an MSIX package) to a user session. Separating out the application from the operating system makes it easier to create a golden virtual machine image, and you get more control with providing the right application for the right user. Previously, you had to use PowerShell scripts to enable MSIX app attach. We will be integrating the app attach capability in the Azure portal and Azure Resource Manager. This will eliminate the need for custom scripts and makes it possible to publish your packaged applications to application groups with a few clicks. Proactive Monitoring Proactively monitoring your deployment is important to ensure your deployment is always up and running and your employees have an optimal experience using virtual desktops. Azure Monitor workbook Azure Monitor workbook for Windows Virtual Desktop aims to provide you all the monitoring telemetry and visualizations you need to debug and troubleshoot issues. You can configure alerts to proactively identify issues before they impact your employees. You can look at connection and host level performance and also drill down to specific user session to see if there are any issues. You can also look at usage across host pools and make sure you are optimizing for cost and performance. Improved Security With Windows Virtual Desktop, you can use security capabilities such as Azure encryption, Azure Firewall, Azure Security Center, and Microsoft Defender to secure your entire VDI infrastructure and ensure that your corporate and customer data is protected and stored securely. We continue to add additional security capabilities: Screen capture protection One common attack vector with remote sessions is screen capture. To protect your sensitive information, we are adding the option to disable screen capture for your remote apps and desktop on all the supported Windows Virtual Desktop clients. Direct RDP to session host We are introducing a new capability that can be set at a host pool level and will take into account the type of network you are connecting from, and when possible, establish a direct peer-to-peer UDP connection to the session host rather than over the internal Windows Virtual Desktop gateways. By eliminating the intermediate hops and using a more efficient connection over a trusted network, you get a secure optimized experience with lesser connection latency and better performance. Thank you again for the amazing feedback that you have provided to us. You can track the progress of these upcoming public previews in our roadmap page. If you are attending Microsoft Ignite conference, you can learn more about these features and get your questions answered in our sessions and you can always reach us anytime at the Windows Virtual Desktop Tech Community page. You can also register here to attend our upcoming webinars.
