Converting HTML to PDF - Inline-Block Elements Don't Work
Hello hansleroy!
Unfortunately, I can't remove those parts. The <img> tag is an image that I need in the final document, and I'm trying to get the <table> and the <img> to display in-line with eachother.
Well, at least something has to be tweaked, no?
At least I'd remove the <table> tags to see if it makes any difference.
Kind regards
Hans
- We're attempting something similar. In our case, generating a HTML file using DIVs to display and image and overlay text on the image. The HTML file is generated correctly, however when converting via the OneDrive step, the overlay text is "stacked up" at the bottom of the PDF. Using the browser print on the HTML file, the text is correctly placed in the PDF. Perhaps this is a bug/limitation of the Convert File step and why still in preview? Curious to know if anyone has successfully accomplished this.
- Wait, so when you take the generated HTML and use the print to PDF function, the text displays correctly?
I honestly haven't tried that, but it does take away from the auto-generated portion of it. I know that I went through and created an HTML document by hand that had all of the correct formatting, and when I copied and pasted it into the Create a Document portion of my flow, a lot of the formatting didn't stick, so I've been working on recreating all of it in that box, to make sure what I have actually works. I'm just getting stuck on the getting the image and text to display in-line!
Any chance I could take a look at your flow, to see how you have it set up?EDIT: updated HTML to include image variable.
McTwitch - the flow is basic right now, just trying to get it to work.
The Get File Content, retrieves the image and the next step loads it into a variable. In the Create File, we build the HTML string, along with the image variable, and save as HTML file to OneDrive. At this point, the HTML displays correctly and we can do a print to PDF from the browser and the PDF matches the HTML. The Convert File, we convert to PDF and then create the PDF in OneDrive, at which point, the text overlay is no longer displaying correctly. It seems like the conversion in Power is breaking the format. Here's a sample of the HTML we're generating (sorry for inline, can't attach .txt to the post):
<!DOCTYPE html>
<html><head><meta name="viewport" content="width=device-width, initial-scale=1">
<style>
.container {position: absolute; text-align: center;color: black;}
.bottom-left {position: absolute; bottom: 8px;left: 16px;}
.top-left {position: absolute;top: 8px;left: 16px;}
.top-right {position: absolute;top: 8px;right: 16px;}
.bottom-right {position: absolute;bottom: 8px;right: 16px;}
.centered {position: absolute;top: 50%;left: 50%;transform: translate(-50%, -50%);}
</style>
</head>
<body>
<h2>Image Text</h2>
<p>How to place text over an image:</p>
<div class="container"><img src="',variables('PDFImage'),'" alt="Snow" style="width:100%;"><div class="bottom-left">Bottom Left</div>
<div class="top-left">Top Left</div>
<div class="top-right">Top Right</div>
<div class="bottom-right">Bottom Right</div>
<div class="centered">Centered</div>
</div></body></html>Hope this helps.
