Authentication Failure for IMAP and POP3 using Client Credential flow for OAuth2.0 | Java
I am facing an authentication failure issue while trying to connect for both IMAP and POP3 protocols using the Client Credential Grant flow for OAuth2.0
Where, I have been following the steps suggested in "https://docs.microsoft.com/en-us/exchange/client-developer/legacy-protocols/how-to-authenticate-an-imap-pop-smtp-application-by-using-oauth#get-an-access-token"
I have been using this github project to fetch the Access Token using Client Credential Grant flow:
https://github.com/Azure-Samples/ms-identity-msal-java-samples/tree/main/1.%20Server-Side%20Scenarios/msal-client-credential-secret
Java Code for IMAP:
public static void connectIMAP(String userEmail, String accessToken){
String SSL_FACTORY = "javax.net.ssl.SSLSocketFactory";
Properties props= new Properties();
props.put("mail.imap.ssl.enable", "true");
props.put("mail.imap.port", "993");
props.put("mail.imap.auth.mechanisms", "XOAUTH2");
props.put("mail.imap.sasl.mechanisms", "XOAUTH2");
props.put("mail.imap.auth.login.disable", "true");
props.put("mail.imap.auth.plain.disable", "true");
props.setProperty("mail.imap.socketFactory.class", SSL_FACTORY);
props.setProperty("mail.imap.socketFactory.fallback", "false");
props.setProperty("mail.imap.socketFactory.port", "993");
props.setProperty("mail.imap.starttls.enable", "true");
props.put("mail.debug", "true");
props.put("mail.debug.auth", "true");
Session session = Session.getInstance(props);
session.setDebug(true);
try {
final Store store = session.getStore("imap");
store.connect("outlook.office365.com",userEmail, accessToken);
if(store.isConnected()){
System.out.println("Connection Established using imap protocol successfully !");
}
} catch (NoSuchProviderException e) { // session.getStore()
e.printStackTrace();
} catch (MessagingException e) { // store.connect()
e.printStackTrace();
}
}
Java code for POP3:
public static void connectPOP(String email, String accessToken){
Properties properties= new Properties();
properties.put("mail.pop3.port", 995);
properties.put("mail.pop3.forgettopheaders", "true");
properties.put("mail.pop3.auth.mechanisms", "XOAUTH2");
properties.put("mail.pop3.auth.login.disable", "true"); // If true, prevents use of the USER and PASS commands. Default is false.
properties.put("mail.pop3.auth.plain.disable", "true"); // If true, prevents use of the AUTH PLAIN command. Default is false.
properties.put("mail.pop3.auth.xoauth2.disable","false"); // If true, prevents use of the AUTHENTICATE XOAUTH2 command. Hence set it to false
properties.put("mail.pop3.auth.xoauth2.two.line.authentication.format", "true"); // If true, splits authentication command on two lines. Default is false.
properties.put("mail.pop3.connectiontimeout", 15000);
properties.put("mail.pop3.timeout", 15000);
properties.put("mail.debug", "true");
Session session = Session.getInstance(properties);
session.setDebug(true);
try{
Store store = session.getStore("pop3");
store.connect("outlook.office365.com", email, accessToken);
if(store.isConnected()){
System.out.println("Connected with pop3 successfully !");
}
}catch(Exception e){
e.printStackTrace();
}
}
Following are the credentials which I have used while performing the Client Credential Grant flow
- userEmail:- Email of the user which is used to login to Azure portal (eg, email address removed for privacy reasons)
- authority=https://login.microsoftonline.com/<tenant - id - here>/
- client_id= <client(application) - id - here>
- secret= <client - secret - key - here>
- scope= https://outlook.office.com/.default
| Note: I have been using the Default Active Directory, and the default user(Admin) for my Azure account. Is it fine this way ? or does it require a new custom Azure AD and a separate tenant for performing client credential flow |
Below Image contains list of permissions I have applied in my app:
Error Logs:
Spoiler *** IMAP *** DEBUG: JavaMail version 1.5.6
DEBUG: JavaMail version 1.5.6 |
Following is the list of jars I have used as a part of this development:
My Java Code Link(ideone): https://ideone.com/2RaWN9
Please help and let me know if the program is not correct.
Or if any important step seems to be missing.
Thank you.
Hi. I had the same problem, but I think I made some progress.
I read documentation few times, tried few times from the start with same error. I even have tried using client and object ids instead of email as username, in lack of better ideas.
So this is where I think I have made mistake previous times.When you are at the part that you need to register service principal, you need to execute
New-ServicePrincipal -AppId <APPLICATION_ID> -ServiceId <OBJECT_ID> [-Organization <ORGANIZATION_ID>]here I put enterprise application object id as ServiceId argument. And that is ok.
But on
Add-MailboxPermission -Identity "email address removed for privacy reasons" -User <SERVICE_PRINCIPAL_ID> -AccessRights FullAccessI have put my registered application object id as User argument. I also tried setting object id of enterprise application, but it did not have success.
I also tried New-ServicePrincipal but with registered app object id as service id, but it gave me the same result.
When I executed
Get-ServicePrincipal -Organization <ORGANIZATION_ID> | flI did not pay attention to ServiceId property, even with documentation specifying it and saying it will be different.
Now I cleared everything and started fresh.
I executed all the steps again, but on the step when I need to add mail permission, I list service principals, and then use `ServiceId` value from the output, as argument for user.
With that, I was able to authorise.
Unfortunately, now I receive `C3 BAD User is authenticated but not connected.` when I try to list inbox. But it is step forward.
I am not sure if you made the same error as me, but maybe it will help you in some way.
I will post info, when I find fix for the new error if somebody comes across same issue.
60 Replies
manish1614 first of all, thanks for your post - it helps me a lot (especially I'm not JAVA developer at all
)Secondly, I would like to return the favor. You looked for the answer about POP3 issue, that it still not authenticate.
If everything is set correctly, you just have to switch to POP3S.
properties.put("mail.pop3s.port", "995"); properties.put("mail.pop3s.ssl.enable", "false"); properties.put("mail.pop3s.starttls.enable", "true"); properties.put("mail.pop3s.starttls.required", "true"); properties.put("mail.pop3s.connectiontimeout", 5000); properties.put("mail.pop3s.timeout", 5000); properties.put("mail.pop3s.partialfetch", false); properties.put("mail.pop3s.auth.mechanisms", "XOAUTH2"); properties.put("mail.pop3s.forgettopheaders", "true"); properties.put("mail.pop3s.sasl.enable", "true"); properties.put("mail.pop3s.sasl.mechanisms", "XOAUTH2"); properties.put("mail.pop3s.auth.login.disable", "true"); properties.put("mail.pop3s.auth.plain.disable", "true");DEBUG: JavaMail version 1.6.2 DEBUG: successfully loaded resource: /META-INF/javamail.default.address.map DEBUG: setDebug: JavaMail version 1.6.2 DEBUG: getProvider() returning javax.mail.Provider[STORE,pop3s,com.sun.mail.pop3.POP3SSLStore,Oracle] DEBUG POP3: mail.pop3s.rsetbeforequit: false DEBUG POP3: mail.pop3s.disabletop: false DEBUG POP3: mail.pop3s.forgettopheaders: true DEBUG POP3: mail.pop3s.cachewriteto: false DEBUG POP3: mail.pop3s.filecache.enable: false DEBUG POP3: mail.pop3s.keepmessagecontent: false DEBUG POP3: mail.pop3s.starttls.enable: true DEBUG POP3: mail.pop3s.starttls.required: true DEBUG POP3: mail.pop3s.finalizecleanclose: false DEBUG POP3: mail.pop3s.apop.enable: false DEBUG POP3: mail.pop3s.disablecapa: false DEBUG POP3: connecting to host "outlook.office365.com", port 995, isSSL true +OK The Microsoft Exchange POP3 service is ready.Unfortunately it's failing then on something else, but at least we were authenticated...
DEBUG POP3: STLS required but not supported QUIT +OK Microsoft Exchange Server POP3 server signing off. javax.mail.AuthenticationFailedException: STLS required but not supportedBut that's another reason to switch to IMAP, and stop using POP3 - pardon POP3S
- Just thanks is not enough, so I'd like to express my heartfelt gratitude for all the effort you put into taking my work one step forward. You did a truly excellent and remarkable work, and I feel fortunate to have someone like you as a collaborator.
Its a very appreciative work you did there by trying to resolve the POP3 related authentication problem. I appreciate your willingness to go above and beyond to help many people out there to achieve their goals.
I had exactly the same problem ; altought i followed the documentation of microsoft.
I have finaly solved it :
when i get request the oauth token, we should put "https://outlook.office365.com/.default" in the scope parameter
but, since it is an uri, it should be encoded (in c# i use UrlEncode)
after that, i was able to use the token in my sasl auth message and then i was authenticated (and got the respons "+OK User successfully authenticated.")
- great to hear that your problem got solved.
Thanks for pointing the UrlEncode trick in C# while assigning the scope param
manish1614
This video explains the necessary steps to solve the problem, pay attention to the PowerShell commandshttps://www.youtube.com/watch?v=bMYA-146dmM&t=356s
- I have not implemented OAuth2.0 still my services works fine. So do I still need to work on implementing OAuth2.0? I am bit confused please help.
If you are still using plaintext IMAP/POP auth, yes you most certainly you do. Microsoft will randomly disable Basic authentication up until the 31st of December 2022. In the interim if Basic Authentication has been disabled on your tenant it can be re-enabled following the following steps. How to temporarily re-enable IMAP plaintext auth in Office 365.
- Login as azure administrator
- Click link: https://aka.ms/PillarEXOBasicAuth
- Click Run Tests
- Select IMAP, click check box, click update
- Hello, I have a question.
We have same code that you have posted, so right now we use application password to connect with outlook and fetch emails. will this stop from 1st oct, do we need to move to OAuth2.0.shrey_soni Yes your understanding is correct, from 1st Oct 2022, you will be required to move to OAuth2 in case you are still using Basic Authentication technique.
Please refer to this post for more information about the announcement.
https://learn.microsoft.com/en-us/exchange/clients-and-mobile-in-exchange-online/deprecation-of-basic-authentication-exchange-online- Thank you manish1614 for answering my question.
- Hi Manish,
I am also having similar issue and spent significant amount of time in searching for proper solution. Can you provide the steps that you followed in setting up the app to resolve the issue. I really appreciate your help. Hi. I had the same problem, but I think I made some progress.
I read documentation few times, tried few times from the start with same error. I even have tried using client and object ids instead of email as username, in lack of better ideas.
So this is where I think I have made mistake previous times.When you are at the part that you need to register service principal, you need to execute
New-ServicePrincipal -AppId <APPLICATION_ID> -ServiceId <OBJECT_ID> [-Organization <ORGANIZATION_ID>]here I put enterprise application object id as ServiceId argument. And that is ok.
But on
Add-MailboxPermission -Identity "email address removed for privacy reasons" -User <SERVICE_PRINCIPAL_ID> -AccessRights FullAccessI have put my registered application object id as User argument. I also tried setting object id of enterprise application, but it did not have success.
I also tried New-ServicePrincipal but with registered app object id as service id, but it gave me the same result.
When I executed
Get-ServicePrincipal -Organization <ORGANIZATION_ID> | flI did not pay attention to ServiceId property, even with documentation specifying it and saying it will be different.
Now I cleared everything and started fresh.
I executed all the steps again, but on the step when I need to add mail permission, I list service principals, and then use `ServiceId` value from the output, as argument for user.
With that, I was able to authorise.
Unfortunately, now I receive `C3 BAD User is authenticated but not connected.` when I try to list inbox. But it is step forward.
I am not sure if you made the same error as me, but maybe it will help you in some way.
I will post info, when I find fix for the new error if somebody comes across same issue.
I just got IMAP to work thanks to this thread.
Be careful to pass the raw token to store.connect() though. The last mistake I did was to process the token as explained in https://learn.microsoft.com/en-us/exchange/client-developer/legacy-protocols/how-to-authenticate-an-imap-pop-smtp-application-by-using-oauth#sasl-xoauth2
But the library already takes care of that.
borist2 Is that Bad user authenticated not connected issue fixed?
- Yes. It was something that I messed up in my code. Thanks.
- This took me back to the documentation to register the service principal in exchange. I was using the registered app's objectId in the New-Service-Principal and Add-MailBox-Permission cmdlets. I changed that to AAD Enterprise Applications's objectId in both commands. With that i'm able to authenticate and read mail from INBOX. The documentation is very confusing in terms of service principal identifier. The documentation says service principal identifier in the Add-MailBox-Permissions is different from the previous one. In my case both are same, which is the Enterprise Application's ObjectId. Thanks a lot for pointing this out. I have been stuck on this for days, now everything is working smoothly 🙂
- All I wanted was to access a mailbox, did not know I was trying to build a nuclear submarine. Microsoft did a terrible job of replacing a trivial process with something incredibly complicated, with multiple steps, and next to none support
I'm having the same issue as well. I've tried every combination of things the documentation provides. If anyone finds a solution, please post it here.
Not sure if it helps you guys but I noticed the first post shows the scope as "https://outlook.office.com/.default" but in this https://docs.microsoft.com/en-us/exchange/client-developer/legacy-protocols/how-to-authenticate-an-imap-pop-smtp-application-by-using-oauth#use-client-credentials-grant-flow-to-authenticate-imap-and-pop-connections:~:text=https%3A//outlook.office365.com/.default it specifically says to use "https://outlook.office365.com/.default".
- DestryHines Thanks for your response, it was a typo which I have corrected now from "https://outlook.office.com/.default" to "https://outlook.office365.com/.default".
I have cross-checked the documentation several times now, but I am still unable to resolve this problem.
manish1614I'm also facing the same issue with IMAP OAuth Authentication with Client Credentials flow. I have followed Microsoft's documentation as you mentioned above. I have given IMAP.AccessAsApp, POP.AccessAsApp permissions, but the access_token is not working with those permissions. Did you find any solution for this?
- Thanks for you reply Anjitha. As of now I have not found any solution for this issue. I will update on the same thread as soon as I find out a working fix for this situation.
- Thank you Manish.
