Recurring Deposit Calculation VBA Code

SP_Pandey  The problem is that you are still compounding monthly in each case.  Here is my suggestion to try:

    ' Calculate maturity value based on selected option button
    If OptionButton1.Value Then ' Monthly mode
        R= 1 + R / 12 ' calculate new rate based on compounding frequency

        N= N \ 1 ' calculates the number of updates to be done base on frequency

        REMAININGPAYMENT = 0 ' calculates any additional payment when frequency has left over

        MONTHLY = MONTHLY * 1 ' calculates the sum of payments for the frequency of interest
    ElseIf OptionButton2.Value Then ' Quarterly mode
        R= 1 + R / 4
        N= N \ 3

        REMAININGPAYMENT = (N MOD 3) * MONTHLY

        MONTHLY = MONTHLY * 3

    ElseIf OptionButton3.Value Then ' Half-Yearly mode
        R= 1 + R / 2

        N= N \ 6

        REMAININGPAYMENT = (N MOD 6) * MONTHLY

        MONTHLY = MONTHLY * 6

    ElseIf OptionButton5.Value Then ' Yearly mode
        R= 1 + R / 1

        N= N \ 12

        REMAININGPAYMENT = (N MOD 3) * MONTHLY

        MONTHLY = MONTHLY * 12

    End If

    Maturity = 0 ' Initial maturity value

    ' Calculate maturity value using the appropriate compounding formula
    For i = 1 To N
        Maturity = (Maturity + Monthly) *  R
    Next i
    Maturity = Maturity + REMAININGPAYMENT
