Microsoft returns to NVIDIA GTC 2026 in San Jose with a strong presence across conference sessions, in‑booth theater talks, live demos, and executive‑level ancillary events. Together with NVIDIA and our partner ecosystem, Microsoft is showcasing how Azure AI infrastructure enables AI training, inference, and production at global scale. Visit us at Booth #521 to see the latest innovations in action and connect with Azure and NVIDIA experts. Exclusive GTC Experiences LEGO® Datacenter Model Explore Azure AI infrastructure at the Park Container. Candy Lounge Visit the high-traffic candy wall for co-branded treats all day long. Networking Lounge Relax and recharge with comfy seating and vital charging options. Outdoor Juice Truck Free, refreshing beverages served during outdoor park hours. Sponsored Breakout Sessions Microsoft Featured Reinventing Semiconductor Design with Microsoft Discovery S82398 · Mon, Mar 16 · 4:00 PM Prashant Varshney Microsoft · Semiconductor & AI Engineering Abstract: Semiconductor teams face exploding design complexity and shrinking verification windows. This session shows how the Microsoft Discovery AI for Science platform, combined with Synopsys Agent Engineers, introduces an agentic approach to EDA that automates routine steps and accelerates expert decision-making on Azure. Microsoft Featured Operationalizing Agentic AI at Hyperscale S82399 · Tue, Mar 17 · 1:00 PM Nitin Nagarkatte Microsoft · Azure AI Infrastructure Anand Raman Microsoft · Azure AI Vipul Modi Microsoft · AI Systems Abstract: As enterprises move to agentic systems, the challenge shifts to operating intelligent agents reliably at scale. This session demonstrates how Microsoft builds AI Factories on Azure using NVIDIA technology and explores Microsoft Foundry as the control plane for deploying and operating coordinated AI agents. Live from GTC: AI Podcast Dayan Rodriguez Corporate Vice President Global Manufacturing and Mobility Alistair Spiers General Manager Azure Infrastructure Live Special Feature A conversation with Microsoft Azure Listen & Subscribe: aka.ms/GTC2026Podcast Scan to Listen Earned Conference Sessions Don't miss these high-impact sessions where Microsoft and NVIDIA leaders discuss the future of AI factories and infrastructure. Mon · Mar 16 5:00 PM Drive Optimal Tokens per Watt on AI Infrastructure Using Benchmarking Recipes Speakers: Paul Edwards, Emily Potyraj Microsoft, NVIDIA Tue · Mar 17 9:00 AM Autonomous AI Factories: Technical Preview of Agent-Native Production Speakers: JP Vasseur, César Martinez Spessot NVIDIA, Microsoft Research Tue · Mar 17 4:00 PM The Road to Intelligent Mobility: Vehicle GenAI Speakers: Raj Paul, Thomas Evans, Bryan Goodman Microsoft, NVIDIA, Bosch Wed · Mar 18 9:00 AM Supercharging AI with Multi-Gigawatt AI Factories Speakers: Gilad Shainer, Peter Salanki, Evan Burness NVIDIA, CoreWeave, Meta, Microsoft Daily Booth Theater Schedule Visit the Microsoft Theater for lightning talks from engineering leaders and partners. Monday, March 16 2:00 PM BTH208 · NVIDIA Accelerate AI Innovation on Azure with NVIDIA Run:ai — Rob Magno 2:30 PM BTH202 · General Robotics Models to Machines: Deploying Agentic AI in Real-World Robotics — Dinesh Narayanan 3:00 PM BTH200 · Fractal Analytics From Generalist to Enterprise-Ready: Fractal Builds Domain AI — C. Chaudhuri, S. Chakraborty 3:30 PM BTH109 · Microsoft Agentic cloud ops - Smarter Operations with Azure Copilot — Jyoti Sharma 4:00 PM BTH103 · Microsoft Build a Deep Research Agent for Enterprise Data — D. Casati, A. Slutsky, H. Alkemade 4:30 PM BTH205 · NetApp Azure NetApp Files: Powering Your Data for AI Capabilities — Andy Chan 5:00 PM BTH207 · NVIDIA The Agentic Commerce Stack: Open Models on Azure — Antonio Martinez 5:30 PM BTH217 · OPAQUE Confidential AI on Azure Unlocks Sovereign AI at Scale — Aaron Fulkerson 6:00 PM BTH218 · Simplismart Making BYOC work at scale with modular inference — Amritanshu Jain 6:30 PM Expo Reception Tuesday, March 17 1:30 PM BTH100 · Microsoft From Open Weights to Enterprise Scale: Open-Source Models — Sharmila Chockalingam 2:00 PM BTH212 · Personal AI Unlocking the power of memory in Teams with Personal AI — Sam Harkness 2:30 PM BTH111 · Microsoft / NVIDIA Scalable LLM Inference on AKS Using NVIDIA Dynamo — Mohamad Al jazaery, Anton Slutsky 3:00 PM BTH204 · Mistral AI Innovate with Mistral AI on Microsoft Foundry — Ian Mathew 3:30 PM BTH104 · Microsoft GPU-Accelerated CFD at Scale: Star-CCM+ on Azure — Jason Scheffelmaer 4:00 PM BTH206 · NeuBird AI Agentic AI for Incident Response on Microsoft Azure — Grant Griffiths 4:30 PM BTH101 · GitHub Agentic DevOps: Evolving software with GitHub Copilot — Glenn Wester 5:00 PM BTH209 · Rescale Real-World AI Physics: GM & NVIDIA on Rescale — Dinal Perera 5:30 PM BTH107 · Microsoft Intro to LoRA Fine-Tuning on Azure — Christin Pohl 6:30 PM Raffle Wednesday, March 18 1:00 PM BTH219 · VAST Data Scaling AI Infrastructure on Azure with VAST Data — Jason Vallery 1:30 PM BTH110 · Microsoft Physical AI and Robotics: The Next Frontier — F. Miller, C. Souche, D. Narayanan 2:00 PM BTH105 · Microsoft Sovereign AI options with Azure Local — Kim Lam 2:30 PM BTH108 · Microsoft Automating HPC Workflows with Copilot Agents — Param Shah 3:00 PM BTH102 · Microsoft Trustworthy Multi-Agent Workflows with Microsoft Foundry — Brian Benz 4:00 PM BTH106 · Microsoft Scaling Enterprise AI on ARO with NVIDIA H100 & H200 — Lachie Evenson 4:30 PM BTH211 · WEKA Hybrid AI Data Orchestration with WEKA NeuralMesh™ — Desiree Campbell 5:00 PM BTH202 · Hammerspace NVIDIA AI Enterprise Software with NIM — Mike Bloom 5:30 PM BTH203 · Kinaxis Reimagining Global Supply Planning with Azure — Dane Henshall 6:00 PM BTH214 · AT&T Connected AI on Azure for Manufacturing — Brad Pritchett 6:30 PM Raffle Thursday, March 19 11:00 AM BTH210 · Wandelbots Physical AI: Powering Software-Defined Automation in Robotics — Marwin Kunz, Martin George 11:30 AM Raffle Explore Our Demo Pods Visit the Microsoft booth to see our technology in action with live demonstrations across four dedicated pod areas. POD 1 Azure AI Infrastructure End‑to‑end AI infrastructure for training and inference at scale, featuring the latest NVIDIA GPU integrations on Azure. POD 2 Microsoft Foundry Our comprehensive platform for building, deploying, and operating agentic AI systems with enterprise reliability. POD 3 Building AI Together Showcasing joint Microsoft and NVIDIA solutions across diverse industries, from manufacturing to retail. POD 4 Startups Powering AI Discover how innovative startups are running next‑generation AI workloads on the Azure platform. Ancillary Events & Networking Join Microsoft leadership and our partner ecosystem at these curated networking experiences. Click the location to view on Bing Maps. Sun · Mar 15 6:00 PM Microsoft for Startups Executive Leadership Dinner 📍 Morton’s Steakhouse, San Jose Exclusive gathering for startup leaders and Microsoft executives. Mon · Mar 16 1:30 PM Microsoft × NVIDIA Open Meet 📍 Signia by Hilton · International Suite Strategic alignment session for Microsoft and NVIDIA executives. Mon · Mar 16 7:30 PM Microsoft + NVIDIA Executive Dinner 📍 Il Fornaio, San Jose Executive dinner for key customers and leadership teams. Tue · Mar 17 7:30 PM Networking in AI & Tech 📍 San Pedro Square Market Community networking mixer for Microsoft teams, partners, and customers. Wed · Mar 18 10:00 AM to 1:00 PM AI Innovator’s Circle Brunch: Powering Intelligent Systems Across the Ecosystem 📍 Il Fornaio, San Jose Hosted by Microsoft & NVIDIA at GTC. Join us for an exclusive brunch and discussion on the intelligent ecosystem.The Hidden Architecture of Nano Architectures
Why does the same prompt, on the same checkpoint, with temperature set to zero, sometimes produce a different answer only when the system is under real load? If you have ever watched token three flip and then watched the whole completion diverge, you already know this is not a product bug. It is a systems fact. Here is the thing. In production, you did not deploy a model. You deployed a runtime that selects an execution plan under constraints. The weights are inside that plan. The behavior is the plan. I’m Hazem Ali — Microsoft AI MVP, Distinguished AI and ML Engineer and Architect, and Founder and CEO of Skytells. I’ve built and led engineering work that turns deep learning research into production systems that survive real-world constraints. I speak at major conferences and technical communities, and I regularly deliver deep technical sessions on enterprise AI and agent architectures. If there’s one thing you’ll notice about me, it’s that I’m drawn to the deepest layers of engineering, the parts most teams only discover when systems are under real pressure. My specialization spans the full AI stack, from deep learning and system design to enterprise architecture and security. A rule I repeat in every serious review is simple. If you cannot explain the runtime, you do not understand the model you deployed. — Hazem Ali This is the next layer after my earlier deep dive on memory, KV cache, paging, and trust boundaries in The Hidden Memory Architecture of LLMs I also break down the memory-and-paging failure modes in When Your LLM Trips the MMU This one goes lower, into the execution that decides which math actually runs. When I Had to Prove It Live I still remember the first time I had to make this concrete in front of a room full of engineers. It was during a technical session I gave, and the question came up in the exact form you’ve probably heard before: Why does the same prompt on the same checkpoint, with temperature set to zero, sometimes produce a different answer only under real load? So I answered it the only way that holds up in a serious engineering room. I didn’t frame it as randomness. I framed it as execution. Not because it sounds cleaner, but because it is the only framing that survives scrutiny: under load, the system is not evaluating the same computation. In production, you don’t deploy weights in isolation. You deploy a runtime that selects an execution plan under constraints. Under load, the constraints change at token cadence: microbatch membership shifts, shapes shift, workspace feasibility tightens, and kernels or algorithms that were legal in the calm regime can become infeasible in the pressured regime. The runtime stays correct by contract, but it executes a different plan. And once the executed plan changes, reduction staging can change. When reduction staging changes, rounding happens at different points. That can move last bits. In decoding, last bits can become different tokens when early logit margins are thin. After the first token flips, divergence is expected because the context is different. That’s what I mean throughout this article when I say: The weights are inside the plan, but the behavior is the plan. What is Happening in Runtime Let’s start with the part most teams skip: the runtime pipeline from admission to a token. A production LLM server is not a function call. It is a control plane. And under real load, it behaves like one. It is not asking “what does the model say.” It is asking “what can I execute right now without breaking my guarantees.” Right now matters. Not in theory, in milliseconds. Because every decode step is a new scheduling event. The system does not commit to a single plan for the entire completion. It keeps re-evaluating feasibility as state shifts. What can I execute at this moment, with the VRAM I still have, on the hardware state I am currently in, while staying inside isolation boundaries and latency targets. That question is not answered once per request. It is answered repeatedly, at token cadence. The queue changes. The batch changes. Memory headroom changes. Cache residency changes. Workspace availability changes. The set of legal kernel and algorithm choices changes with them. And that is the point most people miss. The runtime is not just running your weights. It is continuously selecting an execution plan under constraint. The weights are inside that plan, but behavior lives in the selection. That selection is layered. Admission shapes the effective request. Scheduling forms the batch for this step. Kernel and algorithm choice binds the math that will actually run. Memory residency and allocation decide what is feasible. Isolation rules decide what sharing is allowed. Each layer contributes to the final plan, and the plan is what you are deploying. Admission and shaping Before your prompt ever reaches the model, it gets shaped. Truncation, policy injection, tool schema expansion, routing metadata, tenant tags, prefix reuse decisions, and safety transformations. If you do not know what I mean by effective request, I mean the exact token sequence that the model saw after shaping. That is the only input that matters for reproducibility. Batching and step level scheduling Modern servers do not just batch requests. They batch token steps. In a continuous batching system, token step timing feeds back into batching decisions. A slightly slower step changes who joins the next step. Who joins the next step changes shapes. Shapes change kernels. Kernels change numeric pathways. This is not an opinion. It is why vLLM exists. The PagedAttention paper describes serving as a batching problem where KV cache grows dynamically, wastes memory through fragmentation, and limits batch size. It introduces block level KV management and builds vLLM on top of it as an LLM serving system. Kernel plan selection and library behavior Once shapes are known, the runtime selects kernel variants and library algorithms that are feasible for those shapes and the workspace currently available. This is the part people underestimate. The same operator can have multiple valid implementations. The chosen implementation can change when workspace is tight, when shapes change, or when the engine wants to trade latency for throughput. Memory allocation and residency KV cache, activations, temporary buffers, workspace, graph memory, and communication buffers compete for VRAM. Under pressure, allocation patterns change. Fragmentation changes. Residency changes. Cache locality changes. All of that changes the system timeline and the feasible plan space. If you want a one line summary that is accurate in 2026 production inference, it is this. Inference is a scheduling problem plus a memory residency problem, and the model is inside that. The Scope First, Let me put it very clear. I am not claiming every deployment is nondeterministic. I am not claiming every kernel variant flips tokens. I am not claiming seeds are useless. I am making a narrower claim, the kind you can defend in an incident review without hand waving. Floating point math is not associative. Order matters. When you parallelize, you change the order of operations, and it is therefore valid for parallel results to differ from a sequential evaluation. NVIDIA states this directly in the CUDA C Best Practices Guide. CUDA also makes a foundational guarantee to the hardware and scheduler, not to your intuition. Thread blocks must be able to execute independently, in any order, in parallel or in series. That freedom is part of the programming model, not an edge case (ref). Now connect those two facts. If accumulation order changes, the last bits can change even when every operation is correct, because floating point addition is not associative. NVIDIA explicitly calls this out as well. Then layer in what serving stacks actually do. Production systems intentionally reshape execution through continuous batching and KV memory management. vLLM is a published example of this co design, where serving throughput is achieved by dynamic batching and memory-aware KV handling. Finally, bridge the nano to the semantic. When early logit margins are small, tiny numeric deltas can reorder the top candidates, and a single token flip is enough to diverge the entire completion. Here is the part that should feel a little scary, because it changes what you think you are operating. Under real load, the system is not just slower. It can enter a different execution regime. Batch composition shifts, shapes shift, workspace and residency shift, and the runtime is forced into a different set of legal kernel and algorithm choices. Nothing “breaks.” No bug is required. The system is still correct by contract. But your output is now a property of the regime you are in, not the demo you validated. That means you can pass every determinism test at idle and still ship a system that drifts only when it matters, at p95 and p99, when queues are long and memory headroom is tight. The first time you notice is often a user screenshot, an audit question, or an incident report where two replicas disagree on the same request because the runtime state was not the same. The equation principals should use in incident reviews Most teams ship with the demo mental model. y = f(x, θ) One prompt in, one checkpoint, one output. If the output changes, someone concludes the weights changed, or “AI is random.” That is not how production inference behaves, because production inference is not just a function. It is execution under constraint. Production behavior is closer to this. y = Decode( Exec(θ, x; s) ) θ is still the same weights. But the thing you actually shipped is Exec, and Exec is chosen. It is chosen per step, under the current state of the system. The behavior you observe is the behavior of the executed plan, not the abstract weights. X is not the prompt. X is the effective request. X is the exact token sequence the model saw after shaping. Truncation, policy injection, tool schema expansion, routing metadata, prefix reuse, safety transforms. All of that can change what the model actually receives. If you cannot reconstruct x, you are not replaying the request. You are replaying an approximation. Here is the minimum you should log for x, even if you cannot store raw text: # minimal "x" record: enough to reproduce or prove you cannot trace_x = { "req_id": req_id, "raw_prompt_sha256": sha256(raw_prompt), "effective_text_sha256": sha256(effective_text), "effective_tokens": len(effective_tokens), "truncated": truncated, "trunc_reason": trunc_reason, # e.g., "latency_guard", "context_cap" "decode_cfg_applied": decode_cfg, # temperature/top_p/max_tokens, etc. "shaping_events": events, # ["policy_inject:v3", "tool_schema:v2", ...] } S is not a vibe. S is the execution state that decides the math. S is what principals should demand in a postmortem, because this is what turns “it drifted” into “this plan executed under this regime.” At minimum, s includes: per-step batch composition and shape class queue delays and scheduling outcomes VRAM headroom and workspace availability cache pressure signals precision path and engine fallbacks distributed timeline signals (TP/PP latency, collective stalls) isolation posture (what batching is allowed) Why this matters: in continuous batching, time becomes part of semantics. A few milliseconds of delay changes who gets co-scheduled at the next token step. That changes shapes. Shapes change kernel/algorithm feasibility. Feasibility changes the numeric pathway. When early logit margins are thin, a tiny pathway delta is enough to flip the argmax. Here is a short, practical “s” record you can emit per decode step: # per-step "s" record: what plan ran, under what pressure step_s = { "req_id": req_id, "step": t, "batch_fp": sha256(",".join(sorted(batch_req_ids)))[:12], "shape": f"q=1,k={klen},h={heads},d={hidden},tp={tp}", "queue_ms": queue_ms, "gpu_ms": gpu_ms, "vram_free_mb": vram_free_mb, "workspace_free_mb": workspace_free_mb, "kv_regime": kv_regime, # "normal" | "pressured" | "paged" "precision_path": precision_path, # "bf16" | "fp16" | "tf32" | "fp32" "algo_id": algo_id, # backend/engine specific "kernel_variant": kernel_variant, # if available "isolation_mode": isolation_mode, # "shared" | "strict" } The incident-review translation If you only ask “what prompt did the user send” and “what weights did we run,” you are using the demo equation. You will argue about seeds, debate “randomness,” and never converge. The production equation forces the real question. Which plan executed, under which constraints, and what state pushed us into that plan. The line principals should repeat until teams internalize it is simple. Weights are static. Behavior is a property of the executed plan. And the executed plan depends on state. If you want one more operational layer that makes this feel real, add a regime marker. Regime changes are where “stability” collapses without any bug: def regime(vram_free_mb, paging_on, isolation_strict, queue_p95_ms): if isolation_strict: return "isolation_strict" if paging_on: return "paging" if vram_free_mb < 1024: return "memory_pressured" if queue_p95_ms > 50: return "queue_degraded" return "normal" When the regime changes, the feasible plan space changes. When the plan space changes, the executed math can change. That is the production reality your incident review must be able to explain. Floating point order is where small deltas are born Let’s break it down without hand waving. Finite precision makes rounding part of the computation Floating point math is not real-number math. Every add and multiply is followed by rounding to the representable format you are using. That rounding is not “noise.” It is part of the computation. Once you accept that, one consequence becomes unavoidable. Order matters. NVIDIA states the rule clearly: floating point involves rounding, and when you parallelize you can change operation order, so parallel results may not match sequential results. Why LLM inference is a perfect storm: reductions everywhere Now connect that to what an LLM does at inference time. LLM inference is reduction-heavy by design. Dot products in GEMMs, attention score accumulation, softmax normalization, layer norm statistics, even top-k selection pathways. These are not single operations. They are many partial operations combined into a final scalar or vector. In floating point, the way you combine partials is the outcome. GPU reductions are staged: partial sums, then merges A reduction on GPU is not “a sum.” It is a staged reduction of partials. On a CPU, you can imagine a left-to-right accumulation: ((((a1 + a2) + a3) + a4) + ...) On a GPU, that mental model is wrong. The GPU is built to run thousands of threads. So it computes partial sums in parallel and then merges them in stages. The staging pattern is determined by kernel design and how the backend maps the problem to hardware. Put the figure here, right after the staging idea lands. The staging depends on decisions you do not control at the prompt layer: how data is tiled into blocks how each block maps to warps how many partials each warp reduces whether it uses warp-level primitives, shared memory, or tensor core fragments how the final merge is staged across blocks Change the tile size, or the block shape, or the occupancy, and you often change the staging order. Change the staging order, and you change when rounding happens. You can get two results that are both correct under IEEE floating point rules, and they differ in the last bits. This is not a bug. It is the contract of finite-precision parallel math, applied at scale. Why the last bits move at the core level Floating point addition is not associative under rounding because rounding happens after each operation. The error introduced at each step depends on the magnitude and sign of what you are adding at that step. When you change the staging order, you change: which numbers get added together early which partial sums get rounded early how cancellation behaves when positive and negative terms interact when large and small magnitudes meet, where small values can lose representable impact That is the core mechanism behind “small deltas.” It is not mystical. It is mechanical. Why this shows up in production serving, not in your demo LLM inference is dominated by massive matrix operations and attention. Under the hood, those paths accumulate across large dimensions. An accumulation is exactly where rounding order matters most. And the server does not always run the same kernel variant for those ops. Under load, shape shifts and workspace pressure can push the backend into different implementations. Different implementations often imply different tiling. Different tiling implies different staging. Different staging implies different rounding. Different rounding implies different last bits. So even with an identical prompt, identical checkpoint, and temperature set to zero, you can still see tiny numeric differences when: batch composition changes and produces different effective shapes the engine picks a different algorithm because workspace is tighter the kernel selects a different tile path due to shape class and occupancy the GPU is in a different pressure regime, changing feasibility and scheduling behavior Those deltas are small, but they are real. And in decoding, small can be enough. The bridge from ulps to language: logits, argmax, divergence A tiny last-bit difference is often irrelevant, Until it hits a decision boundary. At decode step t, greedy decoding chooses an argmax. If the top logits are close, a small delta can swap the ordering. Once token t changes, the context changes, and the completion diverges. That is not randomness. That is deterministic branching from a slightly different numerical pathway. So the actionable takeaway is not “GPUs are nondeterministic.” It is this. Parallel math is allowed to produce multiple correct last-bit outcomes, and LLM decoding can amplify those outcomes into different text when margins are thin. CUDA scheduling makes ordering a form of runtime state CUDA makes a stronger statement than most people realize. Thread blocks must be able to run independently. It must be possible to execute blocks in any order, in parallel or in series. That is why the same kernel can execute with different inter block ordering depending on occupancy, contention, and scheduling. Now bring atomics into the picture. Atomics guarantee correctness of each update. They do not guarantee the arrival order of updates across threads and blocks. When floating point updates arrive in different legal orders, the final sum can differ in the last bits, because floating point addition is not associative. If you do not know what atomic add means, here is the useful definition. Atomic add ensures updates do not overwrite each other. It does not ensure which thread gets there first. This is the nano architecture layer that explains a lot of weirdness. Many engineers assume determinism is a property of weights. In practice, determinism is constrained by the legal reorderings of parallel execution. Logit margin is the bridge from ulps to language Now we connect the last bits to a changed sentence. At decode step t, greedy decoding picks the argmax over logits. Let the top two logits be ℓₐ and ℓ_b. Define the margin: mₜ = ℓₐ − ℓ_b A token flip happens when a small perturbation changes the ordering of these top two. If you want an operational translation, it is this. If the model barely prefers token A over token B, a tiny numeric delta can make it prefer B. Once token t changes, the rest of the completion evolves under a different context. Divergence is expected. This is why I keep pushing one instrumentation idea that sounds boring until you need it. Measure early step margins. You cannot manage stability if you never measure how close the decision boundary is. The effective request problem, the quiet killer of reproducibility Here is the pattern I see in almost every serious production investigation. The team replays the user prompt, cannot reproduce the output, and concludes the model is nondeterministic. Then the incident dies in ambiguity. And then, usually too late, someone asks the only question that matters. What did the model actually see. “In every postmortem, I ask one question before I look at weights, kernels, or seeds: what did the model actually see. If we cannot answer that, nothing else is evidence.” - Hazem Ali In production, the user prompt is not the input. It is an ingredient. By the time a request reaches the model, it has passed through a shaping pipeline that exists to keep the system safe, fast, and multi-tenant. That pipeline is not cosmetic. It can change semantics, length, and even decode behavior. The result is the only input that matters for reproducibility. The effective request. This is the same thesis you have already accepted earlier in the article. y = Decode( Exec(θ, x; s) ) If you do not know x, your replay is not valid. If you do not know s, your replay is not comparable. And if you only log the raw prompt, you are logging neither. Shaping changes semantics, not just length Truncation is the obvious one. Under load, systems often cap context length to protect latency and GPU memory. Same prompt, different truncation boundary, different effective context, different output. Nothing “random” happened. You executed a different input. But truncation is only the beginning. Policy injection can prepend or append system text that changes intent. Tool schema expansion can add hundreds or thousands of tokens and push the request over a context boundary. Routing metadata can select a different template. Prefix caching can reconstruct parts of context from cached state rather than raw text. Safety transformations can rewrite or neutralize content. Even small differences here can shift early logits when margins are thin, and this article already showed how small deltas become different tokens. The worst part is that this is silent by default. The user sees their prompt. Engineers see the prompt in logs. The model sees a different token sequence. Then everyone argues about reproducibility using the wrong input. Why this interacts with load, not just correctness Under low load, your system often has enough headroom to be generous. Longer context, fewer cutoffs, stable routing, more consistent batching, and fewer fallbacks. Under real load, shaping becomes defensive. Dynamic truncation thresholds kick in. Tool schema expansions collide with context limits. Prefix reuse behavior changes. Safety gates can become stricter. The same user text can produce a different effective request, and therefore a different output, precisely when the system is under pressure. So if you are only validating reproducibility at idle, you are validating a different system than the one you ship. What principals should require in telemetry If you want strict reproducibility, you must log the execution contract per request. Not the story. The contract. At minimum: effective token count after shaping truncation boundary and reason final merged decode config actually applied policy gates that modified prompt or decode path whether prefix cache was used, and what cache key was referenced routing template version and system message hash If you are privacy constrained, you still can log hashes and structural facts. You do not need raw prompts to diagnose effective request drift. You need verifiable fingerprints. Here is the short version in one line. If you only log the user prompt, you have not logged x. You have logged an approximation of x. And without x, you cannot claim reproducibility. You can only hope for it. Continuous batching, why time becomes part of semantics This is where principal level thinking matters. Continuous batching does not just increase throughput. It changes the execution context at each token step. Batch composition changes shapes. Shapes influence kernel selection and workspace feasibility. Those choices can change reduction structure and rounding pathways. If you want a published anchor, use vLLM. The PagedAttention paper frames high throughput serving as a need to batch many requests, but KV cache grows dynamically and wastes memory through fragmentation. It proposes PagedAttention and builds vLLM on top of it, with block level memory management and flexible sharing of KV cache to reduce memory usage. (arxiv) Here is what this really means in production. The server is selecting which requests share a step. That changes the math shapes. That changes the executed plan. That is why the same prompt behaves differently under load even at temperature zero. Algorithm selection and engine fallback The hidden variability people forget about If you have ever tried to reproduce a drift across replicas and felt like you were chasing ghosts, this is usually the layer you were missing. Libraries and engines choose, Not in a philosophical sense. In a literal, per-operator, per-shape sense. The same attention call is a fork in the road between multiple legal tactics, each with different tiling, different reduction staging, different fusion boundaries, and different temporary memory requirements. Your checkpoint is the same, your prompt is the same, your temperature is zero, and the output still moves because the executed plan moved. PyTorch says the quiet part directly. Disabling cuDNN benchmarking makes cuDNN deterministically select an algorithm, and PyTorch stresses this is different from the deterministic setting. That is the whole story in one sentence: one switch affects how the backend selects an algorithm, another affects whether the selected algorithms are deterministic. Those are separate layers, and under load they can diverge. Now go down to the core of the core. A tactic is not fast or slow. In production serving, a tactic is legal or illegal under the constraints of this token step. The constraint that forces most plan switches is not compute. It is workspace feasibility. Many high-performance kernels need scratch buffers. Some need enough contiguous space to stage tiles, reorder operands, hold partials, or run fused epilogues. When VRAM is fragmented or headroom drops, a tactic becomes impossible even if it is the tactic you validated at idle. The engine does not throw a warning. It simply selects another legal tactic. That is the first uncomfortable point. The second uncomfortable point is what makes this align perfectly with the next section. The constraint is not only “how many MB are free.” The constraint is the memory hierarchy state of the chip. Under load, two replicas can have the same free VRAM and still be in a different regime because the chip is not one pool of memory. It is HBM plus an on-die L2, plus TLBs, plus page tables, plus a fabric that is arbitrating traffic between SMs, L2 slices, and HBM controllers. When that hierarchy shifts, latency per token step shifts. And in continuous batching, a few milliseconds is not a timing detail, it is a scheduling input. This is how a performance event becomes a behavior event without any bug. The engine’s planner sees a world where a tactic that was “best” at idle is no longer best, or no longer feasible, because the chip is in a different pressure state. Your runtime is still correct. It is just operating a different plan in a different regime. One op, multiple legal kernels. The chosen tactic depends on shape class and feasibility. Now bring TensorRT into the picture, because it makes the precision dimension explicit. TensorRT states TF32 Tensor Core usage is not guaranteed and it can fall back to FP32, and it documents configuration controls around TF32. That statement is not about “precision preference.” It is about the reality that precision is part of tactic selection. Precision changes which instructions execute and how accumulation is staged. When your early logit margins are thin, a small pathway delta can swap the argmax at one step. One token flips, and the rest of the completion deterministically diverges. So “temperature zero” is not a determinism guarantee. Temperature governs sampling. It does not pin the execution pathway. If you want a more mechanical anchor, treat matmul the way NVIDIA exposes it: cuBLASLt has a preference descriptor for applying algorithm search preferences and fine-tuning the heuristic function. That is not marketing. That is the API admitting that algorithm selection is a constrained search problem. Now the part that gets rare, and the part most teams never write down. CUDA’s programming model requires that thread blocks be able to execute independently and may execute in any order, in parallel or in series. This matters here because tactic switches often change block geometry and tiling. Different block geometry changes reduction staging. Reduction staging changes where rounding happens. Even if every operation is correct, last bits can move because you legally changed the staging of partial sums. You do not need randomness. You need a different legal staging tree. Now pull security into the same frame, because it is not a separate layer in production. Security posture changes what the scheduler is allowed to do. Isolation constraints reduce batching freedom. Reduced batching freedom increases tail latency. Tail latency pushes you toward tighter admission controls and more aggressive memory behavior. That shrinks the feasible tactic set sooner. In other words, security decisions can move you across regime boundaries faster, which increases plan switching frequency. Stability becomes an SLO dimension of your security posture, not a property of your weights. This is the business consequence that shows up in the worst possible way. So here is the operational rule I use in reviews. If you cannot prove which plan ran, you cannot claim reproducibility. And that leads to the only practical addition that belongs in this section before we move into VRAM bandwidth and cache residency. VRAM bandwidth, cache residency, and why memory hierarchy becomes control plane input Let’s talk about the performance facts that quietly become behavior facts. And yes, I know how complex this gets. I have watched strong staff and principal engineers get lost here, not because they are weak, but because the system crosses too many layers at once: GPU microarchitecture, allocator behavior, kernel tactics, batching policy, and SLO-driven control loops. No single dashboard shows you the full causal chain. That is exactly why I frame it this way. It is not “performance tuning.” It is a coupled control system. So let me break it down cleanly, from the chip outward, until the behavior change becomes inevitable. NVIDIA describes H100 SXM5 as having HBM3 bandwidth around 3 TB/s and an L2 cache of 50 MB designed to reduce trips to HBM by caching repeated accesses. Most teams read that as “the GPU is fast.” In serving, it is more precise to say: the GPU gives you a memory hierarchy with regimes, and your runtime is forced to adapt to whichever regime you are currently in. The chip-level model you should carry in your head Decode is not one big matmul. It is a loop that repeatedly touches a shifting working set: KV blocks for the active sequences attention metadata (block tables, indirection, masks) sampling buffers (logits, top-k/top-p structures) runtime bookkeeping for continuous batching Those accesses are not purely streaming. They are pointer-heavy, and their locality depends on how your KV is laid out, which requests are co-scheduled, and how fragmented your memory becomes under churn. Here is the simplest mental model that is still honest: B_HBM is the number of bytes actually read from HBM during this step. B_L2miss is the number of bytes that missed L2 and therefore had to be fetched from HBM. t_translate is the address-translation tax: extra time from TLB misses and page-table walks. That last term is the one that surprises people. It’s “invisible” until it dominates. Why L2 residency becomes a control-plane input Now connect that to decode, Decode repeatedly reads KV state. If L2 hit rate drops, HBM traffic rises. When HBM traffic rises, stalls rise. When stalls rise, token-step latency shifts. When token-step latency shifts, the server changes batching decisions. This is the control loop you should keep in your head: L2 hit rate ↓ → t_step ↑ → Δt ↑ → batch composition changes → shape class changes → tactic set changes That is the bridge from “cache miss” to “different plan executed.” In continuous batching, time is not just an output metric. Time is an input into the next scheduling decision. A few milliseconds can change who gets co-scheduled at the next token step. That changes shapes. Shapes change feasible kernels and algorithms. That changes the executed math. And if early logit margins are thin, a small pathway delta can flip a token and send the rest of the completion down a different branch. Rare but matters: the translation tax that breaks the “free VRAM” illusion Two replicas can report similar free VRAM and still be in different regimes. Why? Because the chip is not “a pool of memory.” It is an on-die cache, translation structures, page tables, and a fabric that is arbitrating traffic under pressure. When KV is stored in blocks (or pages) and those blocks are scattered due to churn, you often get: worse spatial locality more distinct memory regions per step more TLB pressure more page walks Page walks are not abstract. They are memory reads. They compete with your payload reads. Under real load, this turns into self-inflicted HBM traffic. So you can be “bandwidth rich” on paper and still be “latency poor” in practice because the working set became translation-hostile. This is how a performance event becomes a behavior event without any bug. A concrete KV bandwidth sanity check If you want a back-of-the-envelope check for why decode becomes memory-shaped, use a conservative estimate. Per token step, you often need to read a large portion of KV for the active context. A rough model is: KV bytes per step ≈ 2 × B × L × H × D × s Where: B is batch size (number of sequences co-scheduled in the step) L is current context length (tokens already in KV) H is the number of attention heads (or KV heads, depending on the model) D is head dimension s is bytes per element (2 for fp16/bf16, 1 for int8, etc.) The factor 2 accounts for K and V. Even if your kernel is compute-efficient, you are still moving a lot of bytes. If locality collapses and L2 misses rise, you shift into an HBM-limited regime fast. That is the mechanical reason your p95/p99 step time moves under load, even with the same checkpoint and temperature. Business impact, stated plainly This is why drift shows up where it hurts: p95 and p99. At idle, L2 residency is generous, fragmentation is lower, translation pressure is calmer, and step time is stable. Under load, residency collapses, translation tax rises, allocator feasibility tightens, step time stretches, and your control plane adapts by changing batching and shapes. That can move you into different execution plans without any model change. An enterprise buyer does not care whether you call it “L2 miss driven plan churn.” They care that two identical requests disagree and you cannot explain it. So the takeaway I want principals to internalize is simple: In continuous batching, memory hierarchy state is control-plane state. It shapes latency. Latency shapes batching. Batching shapes shapes. Shapes shape feasibility. Feasibility shapes the executed plan. That is how “performance” becomes “behavior.” Multi node tensor parallel, the execution plan extends across the fabric Once you go multi-node tensor parallel, you add a second execution plane that most teams underestimate. You are no longer operating only a GPU runtime. You are operating a distributed timeline. And the timeline is not a background detail. In continuous batching, the timeline becomes a control input that reshapes batching, shapes, and eventually the executed plan. Let me be precise about what I am claiming, and what I am not. I am not going to claim collectives reorder arithmetic inside a kernel. That would be sloppy. The correct claim is this: Distributed synchronization changes the timeline. The timeline changes admission and batching. Batching changes shapes. Shapes change which plans are legal. That’s enough to explain why the “same prompt, same checkpoint, temp=0” can drift only under real load. The minimal equation you should carry At each decode step, your latency is no longer “GPU time.” It’s GPU time plus fabric time: t_step ≈ t_compute + t_comm + t_sync And the part that hurts is that t_comm and t_sync are not stable. They are affected by contention, queueing, stragglers, and topology. A useful mental model for the communication piece is the classic latency–bandwidth form: t_comm(message) ≈ α + (n / β_eff) α is the per-collective startup and synchronization overhead n is bytes moved β_eff is the effective bandwidth you actually get under contention In isolation, this looks like performance math. In a continuous batching server, this becomes behavior math, because t_step feeds back into the next scheduling decision. What actually happens in multi-node TP at token cadence Tensor parallelism shards the model across devices. Every token step requires cross-device coordination for some portion of the layer execution. In practice, this means collectives become part of the critical path. NCCL’s collective ops are explicit about the semantics: for example, AllReduce reduces values across ranks and returns identical results to all ranks. That tells you what the runtime must do: it must wait for coordination across ranks before progressing. So the decode loop becomes: execute local compute for this step hit a collective boundary wait for the slowest rank to finish and for the fabric to deliver proceed That “slowest rank” detail is the piece people feel but rarely name. In distributed inference, p99 is often a straggler story. A single congested link, a slightly delayed rank, or a transient fabric stall turns into a global stall because collectives synchronize progress. In other words, a multi-node TP system behaves like a coupled oscillator: the fastest GPU is still gated by the slowest collective. Why this changes the executed plan, not just the latency Here’s the bridge to the thesis of the whole article. In a continuous batching server, you do not just execute requests. You continuously reform microbatches at token cadence. That means step time affects who joins the next step. And in multi-node TP, fabric jitter is one of the biggest sources of step-time variability. So when comm jitter shifts t_step, it shifts the schedule: queue delay changes microbatch membership changes effective shape class changes workspace feasibility changes tactic choice changes You already established earlier that a changed shape class can force a different tactic set. Multi-node TP adds a new reason shape churn happens: not only GPU pressure, but fabric timing pressure. So the claim stays clean and defensible: Distributed synchronization doesn’t need to change arithmetic to change behavior. It only needs to change the timeline that drives batching. Chip-to-fabric reality: why infrastructure details belong in the reproducibility record At this scale, the infrastructure is part of the runtime. According to Azure Docs, Azure’s ND H100 v5 series is explicitly positioned for tightly coupled scale-up and scale-out Generative AI and HPC workloads, and it’s built around the idea that the fabric matters, not just the GPUs: If you are running multi-node TP in production, treat fabric telemetry as part of your reproducibility record. Not because it is fun. Because it changes the system timeline that drives batching. A practical minimum is to track per-step: collective type on the critical path (e.g., all-reduce / all-gather) comm time and jitter (p50/p95/p99 per step window) rank skew (max(rank_time) − min(rank_time)) effective bandwidth estimate (n / t_comm) retransmit / congestion signals if your stack exposes them a “fabric regime” marker: normal vs congested vs degraded When drift becomes expensive This is one of the reasons enterprise teams report the most confusing failures only at load. At idle, your timeline is stable, your microbatches are stable, your shapes are stable, and your plan selection is stable. Under real load, the fabric introduces jitter, jitter reshapes batching, batching reshapes shapes, and shapes reshape the executed plan. Now two replicas can disagree, not because the model changed, but because the timeline differed. That shows up as: inconsistent answers across replicas in high-stakes workflows reproducibility failures during audits and incident reviews “regressions” after scaling out, even with the same checkpoint and code support costs and credibility loss because you cannot explain why behavior changed only at p95/p99 So the operational sentence I want you to carry into your postmortems is: In multi-node tensor parallel inference, the execution plan extends across the fabric. If you do not log the fabric timeline, you are missing part of the runtime state that decides which plan was feasible. Where Infrastructure Stops Being “Just Infrastructure” Once you accept the thesis of this article, one conclusion becomes unavoidable: cloud choices are not just cost and convenience decisions. They shape which execution regimes your runtime will enter under pressure. At scale, you are no longer buying “GPUs.” You are buying: A fabric and topology that holds up under synchronized token-step collectives A VM family with predictable characteristics for tightly coupled scale-out workloads (the kind multi-node inference actually is) An isolation posture that can be enforced in hardware when your threat model requires it, without hand-waving away the runtime implications First-class observability for GPU behavior, not just CPU and request traces, so you can correlate drift with the state variables that caused it (for example, exporting NVIDIA DCGM metrics into managed Prometheus and Azure Managed Grafana on AKS). This is the quiet reason certain platforms feel “more stable” in production. Not because the model is different, but because the runtime state is easier to constrain, measure, and explain when the underlying infrastructure is designed for the exact regime you’re operating in. Quantization effects on execution paths and causal stragglers in multi-node TP Let me be direct about what most articles miss when they discuss distributed inference at scale. The conversation typically stops at "how many GPUs" and "what's the bandwidth." That's not wrong. It's just incomplete. What's missing is the interaction between quantization-induced plan churn and straggler amplification in the collective path, two forces that quietly reshape your execution regime under VRAM pressure and fabric contention. These are not theoretical curiosities. They are production realities at 100+ GPU scale, the kind of scale where you can no longer afford to treat quantization as a "precision choice" or stragglers as a "latency outlier." At that scale, they become causal inputs to your runtime's decision surface. Quantization variability: not just precision, but plan selection When teams talk about INT8 or FP8 quantization, the conversation usually centers on memory savings and throughput gains. That's the marketing layer. The execution layer is more nuanced: quantization changes which kernels are legal, where fusion boundaries land, and how reduction trees are staged. Here's what I mean in concrete terms. Under VRAM pressure, your serving stack may need to requantize activations mid-forward-pass to stay within memory bounds. That requant step is not "free" in the plan sense. It introduces: dequant/requant cycles that break fusion opportunities you had in the FP16 path new non-associative operations in the reduction tree, where rounding happens at different stages fallback paths when the quantized kernel variant lacks workspace or doesn't support the current shape class Let me state this in the language of the article's thesis: quantization is not a data type. It is a tactic constraint that reshapes the feasible plan space. Memory pressure can force dequant/requant cycles, change fusion boundaries, and trigger fallback kernels with different reduction staging, producing last-bit differences that can flip tokens during decoding. The practical consequence? Two replicas running "the same quantized model" can execute different kernel variants when one is memory-pressured and the other is not. The memory-pressured replica may be forced into a fallback path with different reduction staging. Different staging means different rounding order. Different rounding order means different last bits. And in decoding, last bits can become different tokens. I've watched incident reviews where teams assumed INT8 was "deterministic" because they set the quantization scheme once at export time. What they missed is that the runtime's quantization pathway depends on the state of VRAM fragmentation, workspace availability, and kernel preference histograms, exactly the regime-dependent variables we've been building toward throughout this article. If you're operating at scale, instrument this. Track: per-step kernel selection via cuBLASLt preference descriptors dequant/requant cycle counts when memory pressure rises fallback events when preferred quantized tactics become infeasible whether the executed plan matched the "expected" quantization pathway This is rare telemetry. Most teams never see it because they're not running large enough clusters under sustained pressure. But once you cross into 100+ GPU inference workloads, quantization-induced plan churn becomes visible in your p99 drift signatures. Causal stragglers: when one rank's fallback stalls the collective Now let's talk about the fabric-scale pathology that couples with everything we just discussed: head-of-line blocking in distributed tensor parallelism. You already know from the multi-node TP section that collectives synchronize progress. The fastest rank waits for the slowest. That's the contract. What's less documented—and what I've only seen formalized in internal NVIDIA serving postmortem templates—is how a single rank's kernel fallback can become a collective-wide straggler, and how that straggler amplifies through the batching feedback loop. Here's the causal chain: One rank enters memory pressure. Maybe fragmentation is worse on that device, maybe it's handling a slightly different KV layout due to request assignment. That rank falls back to a slower tactic. The preferred kernel requires workspace. Workspace isn't available. The engine selects a legal fallback. The fallback kernel takes longer. Not by seconds—by milliseconds. But in a collective, milliseconds matter. The collective waits. AllReduce can't proceed until all ranks contribute. The straggler becomes the bottleneck. Step time stretches. The stretched step reshapes the next batch in continuous batching. Different batch, different shapes, different feasibility. The cycle repeats. Now multiple ranks may be in fallback paths. The p99 drift you're seeing isn't random—it's a feedback loop. This is what I call a causal straggler: not just a slow rank, but a rank whose performance degradation causally reshapes the execution regime of the entire TP group. And here's where quantization and stragglers intersect. If one rank is under more VRAM pressure and is forced into more frequent dequant/requant cycles, it becomes the straggler. Its quantization pathway differs from the other ranks—not because the model changed, but because the memory regime changed. That difference in pathway becomes a difference in step time. That difference in step time becomes a collective stall. That stall becomes a batching change. That batching change becomes a new plan. The output drifts, and you're left wondering why "the same checkpoint at temperature zero" produced different text only under load. The answer is: you weren't in the same execution regime. You were in a regime where one rank's memory pressure caused a straggler, the straggler caused a timeline shift, and the timeline shift caused a plan change. Rarity value: why this knowledge is elite production battle scars Let me be honest about why these gaps are rare. Most teams never operate at the scale where these effects dominate. If you're running inference on 8 GPUs, you might see hints of this. At 100+ GPUs with multi-node TP and continuous batching under sustained load, it's no longer a hint—it's the signature. The teams that do operate at this scale track: cuBLASLt preference histograms to detect when algorithm selection is churning across steps NCCL timeline traces to identify straggler signatures and correlate them with per-rank memory state per-rank kernel fallback events to see when one device is operating a different plan than its peers quantization pathway divergence across ranks under pressure This is the telemetry that doesn't show up in tutorials. It shows up in postmortems at hyperscaler SLO thresholds, where p99 latency violations trigger incident reviews and someone finally asks: "Why did replica 3 disagree with replica 1 only during the peak load window?" The article you're reading now covers single-node memory regimes beautifully. What bridges to 10/10 elite production knowledge is this: fabric-scale causality. The understanding that in multi-node TP, your execution regime is not just shaped by your GPU's memory state—it's shaped by the worst GPU's memory state, because collectives couple everyone's timeline. That's the gap. That's the rarity value. And if you're building or operating inference at 100+ GPU scale, that's the layer where your next outage is hiding. Peak depth: wavefront divergence, tensor core fragmentation, NCCL backpressure, and ISR collision Everything above operates at the principal and staff engineer level. What follows is the layer below that—the chip architect handoff, where you stop talking about "plans" in the abstract and start talking about warp stall cycles, tensor core fragment occupancy, NCCL retransmit chains, and memory evaporation under replication pressure. I'm writing this section because it's the part I never see published outside internal design reviews, and because these are the exact pathologies that turn a well-architected inference cluster into a system that disagrees with itself only during peak traffic. "Most engineers debug the layer they understand. The system breaks at the layer they don't. In production inference, that layer is almost always the one where microarchitecture meets scheduling meets the fabric." — Hazem Ali Wavefront divergence in decode attention kernels Let me take you inside the warp. In SIMT execution, a warp is 32 threads executing in lockstep. When all threads follow the same control path, you get full utilization. When they diverge—different threads take different branches—the warp must serialize both paths. That's textbook GPU architecture. What's not textbook is how this interacts with paged KV attention in production decode loops. In a paged KV system (the exact kind vLLM introduced), KV blocks are scattered across VRAM. Different sequences in the same microbatch may have their KV blocks in different residency states: some hot in L2, some cold in HBM, some partially evicted under paging pressure. When the attention kernel issues loads for KV blocks, threads within the same warp can stall at different rates depending on which blocks they're accessing and where those blocks reside. This creates a subtle but measurable pathology: Lane divergence inside the attention kernel. Not control-flow divergence in the traditional sense, but memory-latency divergence: some lanes return fast (L2 hit), some stall (HBM fetch), and the warp can't retire until the slowest lane completes. Register pressure amplification. When warps stall, the SM must keep their register state live. Under heavy stalling, register pressure rises, which can force the compiler to spill to local memory (which lives in L2/HBM). Spills create more memory traffic, which creates more stalls. It's a feedback loop at the microarchitectural level. Measurable p99 step variance in identical-shape batches. This is the part that confuses teams. Two consecutive decode steps with the same batch size and the same sequence lengths can have different step times, because the KV block residency pattern differed. The shape was identical. The memory topology was not. If you want to see this in practice, the tool is Nsight Systems. What you're looking for: # Nsight Systems trace analysis: partition warp stall cycles # Look for these stall reasons in the GPU metrics view: # - smsp__warps_issue_stalled_long_scoreboard → memory dependency stalls # - smsp__warps_issue_stalled_short_scoreboard → register dependency stalls # - smsp__warps_issue_stalled_no_instruction → instruction cache miss # # Correlate with: # - l1tex__t_sectors_pipe_lsu_mem_global_op_ld → global load sectors (KV fetches) # - lts__t_sectors_srcunit_tex_op_read_hit_rate → L2 hit rate during attention # # The diagnostic signal: when stall_long_scoreboard spikes correlate with # L2 hit rate drops, you're seeing KV residency divergence across warps. The stall partition tells you why the warp stalled. When you see long_scoreboard stalls dominating during attention kernels—and you see them correlating with L2 miss rate fluctuations—you're observing exactly the KV residency divergence I'm describing. The warp is waiting for scattered KV blocks, and the scatter pattern changes with every batch because paging decisions are state-dependent. This is how "identical shapes" produce different timelines. The shape is the same. The KV block map is not. And the block map is a function of runtime allocation history—the same state-dependent variable that drives everything else in this article. Tensor core fragment utilization collapse under shape churn Now let's go inside the tensor cores themselves. H100 and Blackwell tensor cores operate on matrix fragments—fixed-size tiles that map directly to the hardware's matrix multiply-accumulate units. On H100, the native fragment sizes for FP16 are typically 16×16×16 (m×n×k). When your operand dimensions align cleanly with fragment boundaries, you get full utilization. When they don't, you get fragment waste: the hardware still executes full fragments, but some of the lanes carry padding zeros. In continuous batching, shape churn is the norm. Your microbatch dimensions change at token cadence. And this is where a subtle but devastating efficiency collapse hides. Consider two microbatches that arrive one step apart: # Step t: B=16, L=2048 → GEMM shape aligns cleanly with 16×16 fragments # Fragment utilization: ~98% # cuBLASLt selects: WMMA-based kernel (tensor core native) # # Step t+1: B=17, L=2047 → GEMM shape straddles fragment boundaries # Fragment utilization: drops below 25% on trailing tiles # cuBLASLt selects: fallback to non-WMMA FP16 kernel # (or WMMA with heavy padding, depending on heuristic) The difference is one sequence in the batch and one token in context length. The performance consequence is that the runtime switches from tensor core native execution to a scalar FP16 path. That's not a minor variant. That's a fundamentally different instruction mix, a different reduction tree, and a different accumulation order. The ulp deltas that result from this switch don't stay contained in the GEMM output. They propagate forward through layer normalization—which is itself a reduction over the hidden dimension. Layer norm amplifies small differences because it divides by a variance term computed from the same values. A tiny shift in the GEMM output becomes a slightly different variance, which becomes a slightly different normalization, which becomes a slightly different input to the next layer's attention. You can observe this directly via cuBLASLt's algorithm preference reporting: # cuBLASLt algorithm preference histogram (conceptual) # Track per-step which algorithm ID was selected for the primary GEMM # # Healthy (stable shapes): # algo_id=42 (WMMA_TENSOR_OP_HMMA_16816) → 99.2% of steps # algo_id=17 (SIMT_FP16_SPLITK) → 0.8% of steps # # Under shape churn (continuous batching, mixed lengths): # algo_id=42 (WMMA_TENSOR_OP_HMMA_16816) → 61.3% of steps # algo_id=17 (SIMT_FP16_SPLITK) → 22.1% of steps # algo_id=31 (WMMA_TENSOR_OP_PAD16) → 16.6% of steps # # When algo_id distribution churns, your reduction tree is churning. # When your reduction tree churns, your last bits are churning. # When your last bits churn under thin margins, your tokens can flip. That histogram is the smoking gun. When you see algorithm preference distribution widening under load, you're watching the tensor cores get destabilized by shape churn. The fix isn't "use bigger batches." The fix is to understand that continuous batching creates a shape distribution, not a fixed shape, and that shape distribution maps directly to a tactic distribution, which maps directly to a ulp distribution. NCCL causal backpressure chains across TP+DP pods Now scale this to the fabric. Take an 8×TP + 4×DP pod: 32 GPUs total, where every token step requires AllReduce across the 8-way TP group, and gradient synchronization (or KV redistribution in some architectures) across the 4-way DP group. Here's the causal backpressure chain I've traced in production, laid out as a timeline: Rank 5 (of 8 TP ranks) hits a quant/dequant stall. Its KV blocks are fragmented, workspace is tight, and the runtime forces a dequant cycle mid-attention. That adds ~1.2ms to this rank's compute. AllReduce stalls on Rank 5. The other 7 ranks complete their portion and issue their NCCL send. Rank 5 hasn't arrived yet. NCCL's ring/tree protocol can't progress past this rank. Effective t_sync inflates by 2× compared to the no-straggler baseline. P2P retransmit triggers. Under some fabric topologies and congestion states, the delayed arrival from Rank 5 can cause NCCL to hit internal retry logic on the NVLink or InfiniBand path. This is not a "network error"—it's the transport protocol managing flow control under backpressure. But it adds latency jitter that is invisible unless you're tracing at the NCCL bootstrap level. vLLM scheduler reacts to the stretched step. The scheduler sees that step t took 2× longer than expected. Under its latency-aware admission control, it drops batch size from 32 → 12 to protect SLO. Smaller batch means different shapes. Different shapes mean different tactics. The plan changes. The batch size drop propagates. With batch size at 12, queued requests wait longer. Queue pressure builds. When the scheduler recovers and re-admits, the burst creates shape churn. Shape churn destabilizes tensor core fragment utilization. The system is now in a different execution regime—triggered by one rank's memory fragmentation. That is a causal backpressure chain. Not a latency spike. Not a network blip. A causally connected sequence where a microarchitectural event on one device reshapes the execution plan across the entire pod. To trace this, you need NCCL bootstrap traces with NVTX domain annotations: # NCCL tracing with NVTX domains for causal analysis # # Environment setup for trace collection: # NCCL_DEBUG=INFO # NCCL_DEBUG_SUBSYS=INIT,COLL,P2P # NSYS_NVTX_DOMAINS=nccl,cuda,cublas # # In Nsight Systems, correlate: # 1. Per-rank kernel duration (cuda domain) — identify the straggler # 2. NCCL collective start/end (nccl domain) — measure t_sync inflation # 3. P2P transport events (nccl/P2P) — detect retransmit/backpressure # 4. Scheduler batch decisions (application NVTX) — see batch size reaction # # The causal signal: when rank N's kernel duration spike aligns with # NCCL collective inflation across all ranks, followed by batch size # reduction in the scheduler, you have a causal backpressure chain. # # Regex for filtering straggler events in nsys export: # grep -E "ncclAllReduce.*duration_us > (2 * median_duration)" trace.sqlite # → correlate timestamp with scheduler batch_size change events This is the telemetry that separates "we think there was network jitter" from "Rank 5's dequant stall caused a 2× collective inflation that forced the scheduler to halve batch size, which shifted the shape class into a non-WMMA tactic for the next 47 steps." The first is a guess. The second is a causal explanation. And in an incident review at scale, only the second one survives. ISR + checkpoint overlap pathology: memory evaporation under replication pressure This is the deepest pathology in this article, and it almost never surfaces below 512 sequences per second. Large-scale inference deployments use incremental state replication (ISR) for fault tolerance: rather than checkpointing the entire model state, you replicate KV cache deltas and scheduler state to a standby node incrementally, so failover is fast. Separately, many systems run async checkpointing for recovery: periodic snapshots of model and optimizer state written to persistent storage, overlapped with inference to avoid blocking the decode loop. Under normal load, these two systems coexist peacefully. ISR replicates small deltas. Checkpointing writes in the background. Memory headroom is sufficient for both. Under paging pressure—the exact regime we've been discussing throughout this article—they collide. Here's the pathological interaction: The system is under VRAM pressure. KV blocks are being paged (allocated, evicted, re-allocated) at high frequency. Memory headroom is thin. ISR kicks in. It needs to replicate recent KV deltas to the standby. To do this, it must pin certain KV blocks in memory while it serializes and transmits them. Async checkpointing overlaps. The checkpoint writer is also holding references to memory regions it's snapshotting. Under normal conditions, this is fine—there's enough headroom. Under paging pressure, the checkpoint's memory holds compete with ISR's memory holds. Memory evaporation. The combined pinning from ISR + checkpointing temporarily removes KV blocks from the pool available to the decode loop. The pager sees available blocks drop. It may be forced to evict active KV blocks—blocks that are needed for in-flight sequences—to make room. Evicted blocks must be recomputed. When a sequence's KV is evicted mid-collective (during an AllReduce, for example), the rank that lost its KV must recompute it. That recompute makes this rank the straggler. And we already know what stragglers do to the collective timeline. The straggler triggers the full backpressure chain. Collective stall → batch size reduction → shape churn → tactic churn → output drift. All caused by a fault-tolerance mechanism designed to keep you safe. ISR pins KV deltas for replication while async checkpointing pins regions for snapshotting. Under paging pressure, the combined pinning shrinks the decode-available KV pool, forces evictions and recompute, creates stragglers, and cascades into collective stalls → batch reduction → shape/tactic churn → p99 output drift. I call this memory evaporation because from the decode loop's perspective, VRAM that was available simply vanishes for a window of time. The blocks are still physically present—they're held by ISR and the checkpointer, but they're not available to the runtime. The effect is identical to a sudden drop in free VRAM, and the runtime reacts accordingly: it enters a pressured regime. This is why the pathology rarely surfaces below 512 seq/s. At lower throughput, there's enough headroom that ISR and checkpointing never compete meaningfully with the decode loop's memory needs. At high throughput under sustained load, the margins collapse, and the three systems—decode, ISR, checkpoint—start fighting over the same memory. The fix is not "turn off ISR." The fix is to coordinate memory budgets across these three subsystems and to treat ISR and checkpointing as memory consumers that participate in the regime calculation. If your regime function doesn't account for replication and checkpoint holds, it's underestimating pressure, and your system will surprise you at exactly the scale where fault tolerance matters most. # extended regime function accounting for replication and checkpoint pressure def regime_extended(vram_free_mb, paging_on, isolation_strict, queue_p95_ms, isr_pinned_mb, ckpt_pinned_mb, kv_pool_total_mb): effective_free = vram_free_mb - isr_pinned_mb - ckpt_pinned_mb effective_ratio = effective_free / kv_pool_total_mb if kv_pool_total_mb > 0 else 1.0 if isolation_strict: return "isolation_strict" if effective_ratio < 0.05: return "memory_evaporation" # ISR+ckpt collision if paging_on: return "paging" if effective_free < 1024: return "memory_pressured" if queue_p95_ms > 50: return "queue_degraded" return "normal" That "memory_evaporation" regime is the one you never see at idle. It only appears when throughput is high enough that ISR frequency, checkpoint frequency, and decode memory demand all peak simultaneously. And when it appears, it doesn't show up as an OOM. It shows up as a straggler, which shows up as a collective stall, which shows up as a batch size drop, which shows up as a shape change, which shows up as output drift at p99. That's the full causal chain from fault tolerance to token flip. The chip-architect handoff These four pathologies, wavefront divergence, tensor core fragmentation, NCCL backpressure, and ISR collision are what elevate from principal-level operational insight to chip-architect-level systems thinking. They share a common structure: A microarchitectural or infrastructure event occurs that is invisible at the API layer. The event changes the timeline or the memory topology, not the "inputs." The changed timeline or topology feeds back into scheduling, shaping, or tactic selection. The feedback loop produces a different executed plan. The different plan produces a different result that is correct by contract but different by observation. If you're instrumenting at this depth, you're not debugging anymore. You're operating a system where the observability itself is part of the architecture. And if you're carrying the thesis of this article to its logical conclusion: the executed plan is not just a function of the GPU state. It's a function of the warp state, the fragment state, the fabric state, and the replication state—all coupled through continuous batching at token cadence. Security is not a layer, it changes execution Now let’s go deep, because this is where a lot of principal level reviews go wrong. Teams talk about security as confidentiality and correctness as something separate. In multi tenant inference, they couple. IOMMU based GPU isolation and DMA remapping Microsoft documents IOMMU based GPU isolation as a technique to manage how GPUs access system memory, improving security and stability: Microsoft also documents IOMMU DMA remapping, describing how GPUs access memory through logical addresses that are no longer mapped one to one, enabling logically contiguous address ranges through translation: This matters for two reasons. First, it is a real hardware enforced boundary, not a policy checkbox. Second, boundaries introduce overhead and constraints. Constraints change what is allowed. Allowed execution choices shape the plan space. Confidential computing on H100 NVIDIA states that H100 is the first GPU to introduce support for confidential computing and that it can be used in virtualized environments with VMs or Kubernetes based deployments. Azure has also published general availability of confidential VMs with H100, which is the practical deployment side of this posture: Now the key architectural point. When you turn on stronger isolation, you often restrict sharing. You restrict cross tenant microbatching. You add attestation requirements. You change how memory is mapped and protected. That can reduce throughput. Reduced throughput moves you closer to regime boundaries. When the system crosses a regime boundary, the executed plan changes. Security posture becomes an SLO dimension. If you do not test it, you do not know what system you are running. GPU cache side channels, why sharing is not a theoretical risk There is published research that treats GPU caches as a leakage surface. The USENIX Security 2024 paper Invalidate plus Compare presents a timer free GPU cache attack primitive. I will not provide attack recipes. You do not need them to understand the conclusion. If your threat model includes untrusted co tenants, shared microarchitectural resources matter. If you respond by increasing isolation, your execution constraints change. That changes performance and can change the execution regimes your serving stack enters. Security and runtime behavior are coupled. State collapse, the phase transition that looks like model instability If you don’t know what state collapse is, imagine a highway that looks perfectly calm at 2 a.m. Every lane is open. Every car keeps its distance. Your ETA is stable. You run the same route ten times and you get the same arrival time. Then 8:30 a.m. hits. Nothing “broke” in the highway. The asphalt is the same. The speed limit is the same. The cars are the same. But the system crosses a density threshold. One small brake tap becomes a shockwave. Lanes start interacting. Merges become bottlenecks. A single slow truck creates a queue that ripples backwards. Suddenly your ETA isn’t a property of your car anymore. It’s a property of the traffic regime. That is state collapse in production inference. At low load, the system behaves stable. At high load, output drift appears. And teams mislabel it as “model instability,” or “LLM randomness,” or “temperature drift.” Most of the time, it is none of that. It is a phase transition in the runtime. You didn’t change weights. You crossed a regime boundary. What collapses, exactly State collapse is not “everything gets slower.” It is when the control plane loses the degrees of freedom it was using to keep execution consistent. Under low load, the runtime has slack: enough VRAM headroom to keep preferred tactics feasible enough cache residency to keep step times predictable enough scheduling flexibility to keep microbatch composition stable enough workspace contiguity to avoid algorithm fallbacks enough fabric stability (in multi-node TP) to keep step cadence tight Under high load, that slack disappears. The runtime stops being a “fast executor” and becomes a “survival scheduler.” And once it crosses that boundary, it starts making different decisions that are all valid, all correct by contract, and all capable of shifting outputs. This is why it feels like instability: the model hasn’t changed, but the executed plan has. Why this shows up as output drift, not just latency drift Because decoding is a branching process. A small numerical difference that does nothing in a benchmark can flip a token if the margin is thin. One flip changes the context. The context changes the next logits. Now you’re on a different path. So the runtime doesn’t need to be “wrong” to produce different text. It just needs to execute a different legal plan under a different legal regime. That is the whole thesis of this article, condensed into one sentence: Weights are static. Behavior is a property of the executed plan. The executed plan is a function of state. The common triggers that push systems into collapse You can treat these as the usual “threshold crossings” that shrink the feasible plan space: Memory headroom shrinks → feasible tactic set shrinks Preferred kernels often require workspace. When headroom or contiguity drops, tactics become illegal and the engine selects other tactics. Cache residency collapses → stalls rise → step timing drifts L2 hit rate drops, HBM traffic rises, and decode steps stretch. In continuous batching, stretched steps reshape the next batch. Continuous batching shifts the mix and shapes Under load, microbatch membership changes at token cadence. Shape class changes are not cosmetic; they change kernel feasibility. Framework and engine algorithm selection changes depending on settings Autotuning, benchmarking, and backend heuristics mean the “same op” can legally choose different algorithms. Under pressure, the best choice can become infeasible. CUDA execution permits ordering freedom and floating point order sensitivity remains true Parallel staging and legal reordering can shift last bits. Under thin margins, last bits can become different tokens. Nothing here requires a bug. This is what “execution under constraint” looks like. The incident question that stops the hand-waving If you want a more honest incident question, use this: Which execution regime ran, and what constraints pushed us into it? Not “was the prompt the same.” Not “were the weights the same.” Not “did we set temperature to zero.” Regime first. Because state collapse is not a mystery. It’s a threshold. And once you learn to name the threshold, you can instrument it, test it, and stop being surprised by it at p95 and p99. A reproducibility protocol that works for principals, not demos Logging prompts is not reproducibility. It is wishful thinking. If you want to be able to defend behavior, you need to reconstruct the execution state. Log the execution contract Per request, log: effective input length after shaping truncation boundary and reason decode configuration actually applied admission time, queue time, GPU time per step batch fingerprint or at minimum batch identity and shape class memory headroom watermark and whether you were in a pressured allocation regime engine precision mode settings and any fallback relevant flags cuDNN benchmark and deterministic settings if relevant isolation posture, including whether cross tenant batching is permitted Track margins early Track top two logit margins for early steps. Use it as a stability budget. If the margin collapses under a certain prompt family, treat that as a risk surface. Not every prompt is equally stable. Test under regimes, not at idle Do not run determinism tests at idle and call it solved. Test under: sustained concurrency mixed sequence lengths continuous batching realistic memory pressure real isolation posture If you do not do this, you are validating a different system than the one you ship. vLLM’s paper exists precisely because these conditions define the serving problem. Closing If you want production LLM behavior to be explainable, stop treating the model as the whole system. Weights are static. Executed math is selected under constraint. Behavior lives in the gap. You did not deploy weights. You deployed a physics constrained runtime that contains weights. And that runtime is allowed to change the executed plan, because floating point order matters, CUDA scheduling freedom is part of the contract, engines can choose precision pathways, and serving stacks intentionally reshape batching and memory. Acknowledgments While this article dives into the hidden memory mechanics that shape LLM behavior under load, I’m grateful it was peer-reviewed and challenged before publishing. A special thanks for Hammad Atta and Abhilekh Verma for peer-reviewing this piece and challenging it from a security-and-systems angle. If this article resonated, it’s likely because it describes a reality many teams encounter only after an incident: production LLM behavior is a property of the executed plan, and the executed plan is a function of state. If you’re running production inference at scale and observing behavior shifts under load—especially in tail-latency regimes, I’m happy to connect on LinkedIn. I’m open to substantive technical discussion. Thank you for reading. I hope this helps you surface the hidden variables in serving and turn them into telemetry, controls, and repeatable postmortem evidence. And if you’re seeing similar regime transitions or plan churn in your own deployments, I’d be interested to hear how it presents in your stack. — Hazem Ali Microsoft AI MVP, Distinguished AI & ML Engineer / Architect
Centralized cluster performance metrics with ReFrame HPC and Azure Log Analytics
Imagine having several clusters across different environments (dev, test and prod) or planning a migration between PBS and Slurm or porting codes to a different system. They can all seem like daunting tasks. This is where the combination of ReFrame HPC, a powerful and feature rich testing framework, and Azure Log Analytics can help improve confidence and assurance in the performance and accuracy of a system. Here we will look at how to configure ReFrame HPC specifically for Azure: Deploying the required Azure resources, running a test and capturing the results in Log Analytics for analysis. Deploying the required Azure Resources Firstly, deploy the required resources in Azure by using this bicep from GitHub. The deployment includes the creation and configuration of everything required for ReFrame HPC. These resources include a data collection endpoint, a data collection rule and a log analytics workspace. Running ior via ReFrame HPC For the purpose of demonstrating a running test and capturing the results in Azure from start to finish, here is a simple ior test which will run both a read and a write operation against the shared storage. import reframe as rfm import reframe.utility.sanity as sn @rfm.simple_test class SimplePerfTest(rfm.RunOnlyRegressionTest): valid_systems = ["*"] valid_prog_environs = ["+ior"] executable = 'ior' executable_opts = [ '-a POSIX -w -r -C -e -g -F -b 2M -t 2M -s 25600 -o /data/demo/test.bin -D 300' ] reference = { 'tst:hbv4': { 'write_bandwidth_mib': (500, -0.05, 0.1, 'MiB/s'), 'read_bandwidth_mib': (350, -0.05, 0.5, 'MiB/s'), } } @sanity_function def validate_run(self): return sn.assert_found(r'Summary of all tests:', self.stdout) @performance_function('MiB/s') def write_bandwidth_mib(self): return sn.extractsingle(r'^write\s+([0-9]+\.?[0-9]*)', self.stdout, 1, float) @performance_function('MiB/s') def read_bandwidth_mib(self): return sn.extractsingle(r'^read\s+([0-9]+\.?[0-9]*)', self.stdout, 1, float) Test explanation Set the binary to be executed to ior, along with its arguments. executable = 'ior' executable_opts = [ '-a POSIX -w -r -C -e -g -F -b 2M -t 2M -s 25600 -o /data/demo/test.bin -D 300' ] Specify which systems the test should run on. In this case, any system/cluster which is known to have ior available will be selected. Look at the ReFrame HPC documentation to get a better understanding of the options available for use. valid_systems = ["*"] valid_prog_environs = ["+ior"] Verify the stdout of the job by searching for a specific value to assert that it ran successfully. @sanity_function def validate_run(self): return sn.assert_found(r'Summary of all tests:', self.stdout) If the sanity function passed it will then extract the performance metrics from the stdout of the job. The naming of the methods is important, as they will be stored in the results later. @performance_function('MiB/s') def write_bandwidth_mib(self): return sn.extractsingle(r'^write\s+([0-9]+\.?[0-9]*)', self.stdout, 1, float) @performance_function('MiB/s') def read_bandwidth_mib(self): return sn.extractsingle(r'^read\s+([0-9]+\.?[0-9]*)', self.stdout, 1, float) Performance references are used to determine if the current cluster has met the requirement or not. It also allows margins to be specified in either direction. reference = { 'tst:hbv4': { 'write_bandwidth_mib': (500, -0.05, 0.1, 'MiB/s'), 'read_bandwidth_mib': (350, -0.05, 0.5, 'MiB/s'), } } ReFrame HPC Configuration The ReFrame HPC configuration is key to determine how and where the test will run. It is also where the logic allowing Reframe HPC to use Azure for centralized logging will be defined. The full configuration file is vast and is covered in detail within the ReFrame HPC documentation. For the purpose of this test an example can be found on GitHub. Below is a breakdown of the key parts that allow Reframe HPC to push its results into Azure Log Analytics. Logging Handler The most important part of this configuration is the logging section, without it ReFrame HPC will not attempt to log the results. A handler_perflog of type httpjson is added to enable the logs to be sent to a HTTP endpoint with specific values which our covered below. 'logging': [ { 'perflog_multiline': True, 'handlers_perflog': [ { 'type': 'httpjson', 'url': 'REDACTED', 'level': 'info', 'debug': False, 'extra_headers': {'Authorization': f'Bearer {_get_token()}'}, 'extras': { 'TimeGenerated': f'{datetime.now(timezone.utc).isoformat()}', 'facility': 'reframe', 'reframe_azure_data_version': '1.0', }, 'ignore_keys': ['check_perfvalues'], 'json_formatter': _format_record } ] } Multiline Perflog To ensure this works with Azure, enable perflog_multiline. This will ensure a single record per metric is sent to Log Analytics. This is the cleanest way to output the results. Having this set to False will move the metric names into column names, which means that the schema will be different for each test and will become hard to maintain. Extra Headers A bearer token is required to authenticate the request. ReFrame HPC allows the adding of headers via the extra_headers property and a simple Python function, which obtains a scoped token that can be appended to the additional header. def _get_token(scope='https://monitor.azure.com/.default') -> str: credential = DefaultAzureCredential() token = credential.get_token(scope) return token.token Url Structure The url can be found in the output of the bicep which was run previously. It can also be obtained via the portal. Here is the structure of the url for reference. '${dce.properties.logsIngestion.endpoint}/dataCollectionRules/${dcr.properties.immutableId}/streams/Custom-${table.name}?api-version=2023-01-01' json Formatter A small work around is needed as the Data Collection Rule expects an array of items and ReFrame HPC outputs a single record. To resolve this another Python function can be used which simply wraps the record up in an array. In this example it also tidys up and removes some items that are not required and would cause issues with the json serialization. def _format_record(record, extras, ignore_keys): data = {} for attr, val in record.__dict__.items(): if attr in ignore_keys or attr.startswith('_'): continue data[attr] = val data.update(extras) return json.dumps([data]) Running the Test Now that the infrastructure has been deployed, the test has been defined and is correctly configured, we can run the test. Start by logging in. Here I am using the managed identity of the node, but User auth and User Assigned Managed Identities are also supported. $ az login --identity ReFrame HPC can be installed via Spack or Python and, while I am using Spack for packages on the cluster, I find the simplest approach is to activate a Python environment and install ReFrame HPC along with test specfic Python dependencies. $ python3 -m venv .venv $ . .venv/bin/activate $ python -m pip install -U pip $ pip install -r requirements.txt Now using the ReFrame HPC cli, the test can be run using the configuration file and the test file. $ reframe -C config.py -c simple_perf.py --performance-report -r ReFrame HPC will now run the test against the system/cluster defined in the configuration. For this example it is a Slurm cluster on a partition of HBv4 nodes and running squeue clarifys that. $ squeue JOBID PARTITION NAME USER ST TIME NODES NODELIST(REASON) 955 hbv4 rfm_Simp jim.pain R 0:28 1 tst4-hbv4-97 Results And there we have it, results are now appearing in Azure! From here we can use kql to query and filter the results. This is just a subset of the values available but the dataset is vast and includes a huge range of values that are extremely helpful. Summary By standardizing on the combination of ReFrame HPC and Azure Log Analytics for testing and reporting of performance data across our clusters, whether Slurm based, Azure CycleCloud or existing on-prem clusters, you can gain unprecendented visibility and confidence in the systems you manage and the codes you deploy that were previously hard to obtain. Enabling the potential for: 🔎Fast cross-cluster comparisions 📈Trend analysis over long running periods 📊Standardized metrics regardless of scheduler or system ☁️Unified monitoring and reporting across clusters ReFrame HPC is suitable for a wide range of testing, so if testing is something you have been looking to implement, take a look at ReFrame HPCComprehensive Nvidia GPU Monitoring for Azure N-Series VMs Using Telegraf with Azure Monitor
Unlocking Nvidia GPU Monitoring for Azure N-Series VMs with Telegraf and Azure Monitor. In the world of AI and HPC, optimizing GPU performance is critical for avoiding inefficiencies that can bottleneck workflows and drive up costs. While Azure Monitor tracks key resources like CPU and memory, it falls short in native GPU monitoring for Azure N-series VMs. Enter Telegraf—a powerful tool that integrates seamlessly with Azure Monitor to bridge this gap. In this blog, discover how to harness Telegraf for comprehensive GPU monitoring and ensure your GPUs perform at peak efficiency in the cloud.Scaling physics-based digital twins: Neural Concept on Azure delivers a New Record in Industrial AI
Automotive Design and the DrivAerNet++ Benchmark In automotive design, external aerodynamics have a direct impact on performance, energy efficiency, and development cost. Even small reductions in drag can translate into significant fuel savings or extended EV range. As development timelines accelerate, engineering teams increasingly rely on data-driven methods to augment or replace traditional CFD workflows. MIT’s DrivAerNet++ dataset is the largest open multimodal dataset for automotive aerodynamics, offering a large-scale benchmark for evaluating learning-based approaches that capture the physical signals required by engineers. It includes 8,000 vehicle geometries across 3 variants (fastback, notchback and estate-back) and aggregates 39 TB of high-fidelity CFD outputs such as surface pressure, wall shear stress, volumetric flow fields, and drag coefficients. Benchmark Highlights Neural Concept trained its geometry-native Geometric Regressor, designed to handle any type of engineering data. The benchmark was executed on Azure HPC infrastructure to evaluate the capabilities of the geometry-native platform under transparent, scalable, and fully reproducible conditions. Surface pressure: Lowest prediction error recorded on the benchmark, revealing where high- and low-pressure zones form. Wall shear stress: Outperforming all competing methods to detect flow attachment and separation for drag and stability control. Volumetric velocity field: More than 50% lower error than previous best, capturing full flow structure for wake stability analysis. Drag coefficient Cd: R² of 0.978 on the test set, accurate enough for early design screening without full CFD runs. Dataset Scale and Ingestion: 39 TB of data was ingested into Neural Concept’s platform through a parallel conversion task with 128 workers and 5 GB RAM each that finished in about 1 hour and produced a compact 3 TB dataset in the platform’s native format. Data Pre Processing: Pre-processing the dataset required both large-scale parallelization and the application of our domain-specific best practices for handling external aerodynamics workflows. Model Training and Deployment: Training completed in 24 hours on 4 A100 GPUs, with the best model obtained after 16 hours. The final model is compact and real-time predictions can be served on a single 16 GB GPU for industrial use. Neural Concept outperformed all other competing methods, achieving state-of-the-art performance prediction on all metrics and physical quantities within a week: “Neural Concept’s breakthrough demonstrates the power of combining advanced AI with the scalability of Microsoft Azure,” said Jack Kabat, Partner, Azure HPC and AI Infrastructure Products, Microsoft. “By running training and deployment on Azure’s high-performance infrastructure — specifically the NC A100 Virtual Machine— Neural Concept was able to transform 39 terabytes of data into a production-ready workflow in just one week. This shows how Azure accelerates innovation and helps automotive manufacturers bring better products to market faster.” For additional benchmark metrics and comparisons, please refer to the Detailed Quantitative Results section at the end of the article. From State-Of-The-Art Benchmark Accuracy to Proven Industrial Impact Model accuracy alone is necessary, but not sufficient for industrial impact. Transformative gains at scale and over time are only revealed once high-performing models are deployed into maintainable and repeatable workflows across organizations. Customers using Neural Concept’s platform have achieved: 30% shorter design cycles $20M in savings on a 100,000-unit vehicle program These outcomes fundamentally result from a transformed, systematic approach to design, unlocking better and faster data-driven decisions. The Design Lab interface, described in the next section, is at the core of this transformation. Within Neural Concept’s ecosystem, validated geometry and physics models can be deployed directly into the Design Lab - a collaborative environment where aerodynamicists and designers evaluate concepts in real time. AI copilots provide instant performance feedback, geometry-aware improvement suggestions, and live KPI updates, effectively reconnecting aerodynamic analysis with the pace of modern vehicle design. CES 2026: See how OEMs are transforming product development with Engineering Intelligence Neural Concept and Microsoft will showcase how AI-native aerodynamic workflows can reshape vehicle development — from real-time design exploration to enterprise-scale deployment. Visit the Microsoft booth to see DrivAerNet++ running on Azure HPC and meet the teams shaping the future of automotive engineering. Visit Microsoft Booth to find out more Neural Concept’s executive team will also be at CES to share flagship results achieved by leading OEMs and Tier-1 suppliers already using the platform in production. Learn more on: https://www.neuralconcept.com/ces-2026 Credits Microsoft: Hugo Meiland (Principal Program Manager), Guy Bursell (Director Business Strategy, Manufacturing), Fernando Aznar Cornejo (Product Marketing Manager) and Dr. Lukasz Miroslaw (Sr. Industry Advisor) Neural Concept: Theophile Allard (CTO), Benoit Guillard (Senior ML Research Scientist), Alexander Gorgin (Product Marketing Engineer), Konstantinos Samaras-Tsakiris (Software Engineer) Detailed Quantitative Results In the sections that follow, we share the results obtained by applying Neural Concept’s aerodynamics predictive model training template to Drivaernet++. We evaluated our model’s prediction errors using the official train/test split and the standard evaluation strategy. For comparison, metrics from other methods were taken from the public leaderboard. We reported both Mean Squared Error (MSE) and Mean Absolute Error (MAE) to quantify prediction accuracy. Lower values for either metric indicate closer agreement with the ground truth simulations, meaning better predictions. 1. Surface Field Predictions: Pressure and Wall Shear Stress We began by evaluating predictions for the two physical quantities defined on the vehicle surface. Surface Pressure The Geometric Regressor achieved substantially better performance than all existing methods in predicting surface pressure distribution. Rank Deep Learning Model MSE (*10-2, lower = better) MAE (*10-1, lower = better) #1 Neural Concept 3.98 1.08 #2 GAOT (May 2025) 4.94 1.10 #3 FIGConvNet (February 2025) 4.99 1.22 #4 TripNet (March 2025) 5.14 1.25 #5 RegDGCNN (June 2024) 8.29 1.61 Table 1: Neural Concept’s Geometric Regressor predicts surface pressure more accurately than previously published state-of-the-art methods. The dates indicate when the competing model architectures were published. Figure 1: Side-by-side comparison of the ground truth pressure field (left), Neural Concept model’s prediction (middle), and the corresponding error for a representative test sample (right). Wall Shear Stress Similarly, the model delivered top-tier results, outperforming all competing methods. Rank Deep Learning Model MSE (*10 -2 , lower = better) MAE (*10 -1 , lower = better) #1 Neural Concept 7.80 1.44 #2 GAOT (May 2025) 8.74 1.57 #3 TripNet (March 2025) 9.52 2.15 #4 FIGConvNet (Feb. 2025) 9.86 2.22 #5 RegDGCNN (June 2024) 13.82 3.64 Table 2: Neural Concept’s Geometric Regressor predicts wall shear stress more accurately than previously published state-of-the-art methods. Figure 2: Side-by-side comparison of the ground truth magnitude of the wall shear stress, Neural Concept model’s prediction, and the corresponding error for a representative test sample. Across both surface fields (pressure and wall shear stress), the Geometric Regressor achieved the lowest MSE and MAE by a clear margin. The baseline methods represent several high-quality and recent academic work (the earliest being from June 2024), yet our architecture established a new state-of-the-art in predictive performance. 2. Volumetric Predictions: Velocity Beyond surface quantities, DrivAerNet++ provides 3D velocity fields in the flow volume surrounding the vehicle, which we also predicted using the Geometric Regressor. Rank Deep Learning Model MSE (lower = better) MAE (*10 -1 , lower = better) #1 Neural Concept 3.11 9.22 #2 TripNet (March 2025) 6.71 15.2 Table 3: Neural Concept’s Geometric Regressor predicts velocity more accurately than the previously published state-of-the-art method. The illustration below shows the velocity magnitude for two test samples. Note that only a single 2D slice of the 3D volumetric domain is shown here, focusing on the wake region behind the car. In practice, the network predicts velocity at any location within the full 3D domain, not just on this slice. Figure 3: Velocity magnitude for two test samples, arranged in two columns (left and right). For each sample, the top row displays the simulated velocity field, the middle row shows the prediction from the network, and the bottom row presents the error between the two. 3. Scalar Predictions: Drag Coefficient The drag coefficient (Cd) is the most critical parameter in automotive aerodynamics, as reducing it directly translates to lower fuel consumption in combustion vehicles and increased range in electric vehicles. Using the same underlying architecture, our model achieved state-of-the-art performance in Cd prediction. In addition to MSE and MAE, we reported the Maximum Absolute Error (Max AE) to reflect worst-case accuracy. We also included the Coefficient of Determination (R² score), which measures the proportion of variance explained by the model. An R² value of 1 indicates a perfect fit to the target data. Rank Deep Learning Model MSE (*1e-5) MAE (*1e-3) Max AE (*1e-2) R² #1 Neural Concept 0.8 2.22 1.13 0.978 #2 TripNet 9.1 7.19 7.70 0.957 #3 PointNet 14.9 9.60 12.45 0.643 #4 RegDGCNN 14.2 9.31 12.79 0.641 #5 GCNN 17.1 10.43 15.03 0.596 On the official split, the model shows tight agreement with CFD (R² of 0.978) across the test set, which is sufficient for early design screening where engineers need to rank variants confidently and spot meaningful gains without running full simulations for every change. 4. Compute Efficiency and Azure HPC&AI Collaboration Executing the full DrivAerNet++ benchmark at industrial scale required Neural Concept’s full software and infrastructure stack combined with seamless cloud integration on Microsoft Azure to dynamically scale computing resources on demand. The entire pipeline runs natively on Microsoft Azure and can scale within minutes, allowing us to process new industrial datasets that contain thousands of geometries without complex capacity planning. Dataset Scale and Ingestion DrivAerNet++ dataset contains 8000 car designs along with their corresponding CFD simulations. The raw dataset occupies approximately 39TB of storage. Generating the simulations required a total of about 3 million CPU hours by MIT’s DeCoDE Lab. Ingestion into Neural Concept’s platform is the first step of the pipeline. To convert the raw data into the platform’s native format, we use a Conversion task that transforms raw files into the platform’s optimized native format. This task was parallelized with 128 workers; each allocated 5 GB of RAM. As a result, the entire conversion process was completed in approximately one hour only. After converting the relevant data (car geometry, wall shear stress, pressure, and velocity), the full dataset occupies approximately 3 TB in Neural Concept’s native format. Data Pre-Processing Pre-processing the dataset required both large-scale parallelization and the application of our domain-specific best practices. During this phase, workloads were distributed across multiple compute nodes with peak memory usage reaching approximately 1.5 TB of RAM. The pre-processing pipeline consists of two main stages. In the first stage, we repaired the car meshes and pre-computed geometric features needed for training. The second stage involved filtering the volumetric domain and re-sampling points to follow a spatial distribution that is more efficient for training our deep learning model. We scaled the compute resources so that each of the two stages in the pipeline completes in 1 to 3 hours when processing the full dataset. The first stage is the most computationally intensive. To handle it efficiently, we parallelized the task across 256 independent workers, each allocated 6 GB of RAM. Model Training and Deployment While we use state-of-the-art hardware for training, our performance gains come primarily from model design. Once trained, the model remains lightweight and cost-effective to run. Training was performed on Azure Standard_NC96ads_A100_v4 node, which provided access to four A100 GPUs, each with 80 GB of memory. The model was trained for approximately 24 hours. Neural Concept’s Geometric Regressor achieved the best reported performance on the official benchmark for surface pressure, wall shear stress, volumetric velocity and drag prediction.
mpi-stage: High-Performance File Distribution for HPC Clusters
When running containerized workloads on HPC clusters, one of the first problems you hit is getting container images onto the nodes quickly and repeatably. A .sqsh is a Squashfs image (commonly used by container runtimes on HPC). In some environments you can run a Squashfs image directly from shared storage, but at scale that often turns the shared filesystem into a hot spot. Copying the image to local NVMe keeps startup time predictable and avoids hundreds of nodes hammering the same source during job launch. In this post, I'll introduce mpi-stage, a lightweight tool that uses MPI broadcasts to distribute large files across cluster nodes at speeds that can saturate the backend network. The Problem: Staging Files at Scale On an Azure CycleCloud Workspace for Slurm cluster with GB300 GPU nodes, I needed to stage a large Squashfs container image from shared storage onto each node's local NVMe storage before launching training jobs. At small scale you can often get away with ad-hoc copies, but once hundreds of nodes are all trying to read the same source file, the shared source filesystem quickly becomes the bottleneck. I tried several approaches: Attempt 1: Slurm's sbcast Slurm's built-in sbcast seemed like the natural choice. In my quick testing it was slower than I wanted, and the overwrite/skip-existing behavior didn't match the "fast no-op if already present" workflow I was after. I didn't spend much time exploring all the configuration options before moving on. Attempt 2: Shell Script Fan-Out I wrote a shell script using a tree-based fan-out approach: copy to N nodes, then each of those copies to N more, and so on. This worked and scaled reasonably, but had some drawbacks: Multiple stages: The script required orchestrating multiple rounds of copy commands, adding complexity Source filesystem stress: Even with fan-out, the initial copies still hit the source filesystem simultaneously — a fan-out of 4 meant 4 nodes competing for source bandwidth Frontend network: Copies went over the Ethernet network by default — I could have configured IPoIB, but that added more setup The Solution: MPI Broadcasts The key insight was that MPI's broadcast primitive (MPI_Bcast) is specifically optimized for one-to-many data distribution. Modern MPI implementations like HPC-X use tree-based algorithms that efficiently utilize the high-bandwidth, low-latency InfiniBand network. With mpi-stage: Single source read: Only one node reads from the source filesystem Backend network utilization: Data flows over InfiniBand using optimized MPI collectives Intelligent skipping: Nodes that already have the file (verified by size or checksum) skip the copy entirely Combined, this keeps the shared source (NFS, Lustre, blobfuse, etc.) from being hammered by many concurrent readers while still taking full advantage of the backend fabric. How It Works mpi-stage is designed around a simple workflow: The source node reads the file in chunks and streams each chunk via MPI_Bcast. Destination nodes write each chunk to local storage immediately upon receipt. This streaming approach means the entire file never needs to fit in memory — only a small buffer is required. Key Features Pre-copy Validation Before any data is transferred, each node checks if the destination file already exists and matches the source. You can choose between: Size check (default): Fast comparison of file sizes—sufficient for most use cases Checksum: Stronger validation, but requires reading the full file and is therefore slower If all nodes already have the correct file, mpi-stage completes in milliseconds with no data transfer. Double-Buffered Transfers The implementation uses double-buffered, chunked transfers to overlap network communication with disk I/O. While one buffer is being broadcast, the next chunk is being read from the source. Post-copy Validation Optionally verify that all nodes received the file correctly after the copy completes. Single-Writer Per Node The tool enforces one MPI rank per node to prevent filesystem contention and ensure predictable performance. Real-World Performance In one run using 156 GPU nodes, distributing a container image achieved approximately 3 GB/s effective distribution rate (file_size/time), completing in just over 5 seconds: [0] Copy required: yes [0] Starting copy phase (source writes: yes) [0] Copy complete, Bandwidth: 3007.14 MB/s [0] Post-validation complete [0] Timings (s): Topology check: 5.22463 Source metadata: 0.00803746 Pre-validation: 0.0046786 Copy phase: 5.21189 Post-validation: 2.2944e-05 Total time: 5.2563 Because every node writes the file to its own local NVMe, the cumulative write rate across the cluster is roughly this number times the node count: ~3 GB/s × 156 ≈ ~468 GB/s of total local writes. Workflow: Container Image Distribution The primary use case is distributing Squashfs images to local NVMe before launching containerized workloads. Run mpi-stage as a job step before your main application: #!/bin/bash #SBATCH --job-name=my-training-job #SBATCH --ntasks-per-node=1 #SBATCH --exclusive # Stage the container image srun --mpi=pmix ./mpi_stage \ --source /shared/images/pytorch.sqsh \ --dest /nvme/images/pytorch.sqsh \ --pre-validate size \ --verbose # Run the actual job (from local NVMe - much faster!) srun --container-image=/nvme/images/pytorch.sqsh ... mpi-stage will create the destination directory if it doesn't exist. If your container runtime supports running the image directly from shared storage, you may not strictly need this step—but staging to local NVMe tends to be faster and more predictable at large scale. Because of the pre-validation, you can include this step in every job script without penalty—if the image is already present, it completes in milliseconds. Getting Started git clone https://github.com/edwardsp/mpi-stage.git cd mpi-stage make For detailed usage and options, see the README. Summary mpi-stage started as a solution to a very specific problem—staging large container images efficiently across a large GPU cluster—but the same pattern may be useful in other scenarios where many nodes need the same large file. By using MPI broadcasts, only a single node reads from the source filesystem, while data is distributed over the backend network using optimized collectives. In practice, this can significantly reduce load on shared filesystems and cloud-backed mounts, such as Azure Blob Storage accessed via blobfuse2, where hundreds of concurrent readers can otherwise become a bottleneck. While container images were the initial focus, this approach could also be applied to staging training datasets, distributing model checkpoints or pretrained weights, or copying large binaries to local NVMe before a job starts. Anywhere that a “many nodes, same file” pattern exists is a potential fit. If you're running large-scale containerized workloads on Azure HPC infrastructure, give it a try. If you use mpi-stage in other workflows, I'd love to hear what worked (and what didn't). Feedback and contributions are welcome. Have questions or feedback? Leave a comment below or open an issue on GitHub.
Azure V710 V5 Series -AMD Radeon GPU - Validation of Siemens CAD -NX
Overview of Siemens NX Siemens NX is a next-generation integrated CAD/CAM/CAE platform used by aerospace, automotive, industrial machinery, energy, medical, robotics, and defense manufacturers. It spans: Complex 3D modeling Assemblies containing thousands to millions of parts Surfacing and composites Tolerance engineering CAM and machining simulation Integrated multi physics through Simcenter / NX Nastran Because NX is used to design real-world engineered systems — aircraft structures, automotive platforms, satellites, robotic arms, injection molds — its usability and performance directly affect engineering velocity and product timelines. NX Needs GPU Acceleration NX is highly visual. It leans heavily on: OpenGL acceleration Shader-based rendering Hidden line removal Real-time shading / material rendering Ray-Traced Studio for photorealistic output Switch shading modes → CAD content must stay readable Zoom, section, annotate → requires stable frame pacing NVads V710 v5-Series on Azure The NVads V710 v5-series virtual machines on Azure are designed for GPU-accelerated workloads and virtual desktop environments. Key highlights: Hardware Specs: o GPU: AMD Radeon™ Pro V710 (up to 24 GiB frame buffer; fractional GPU options available). o CPU: AMD EPYC™ 9V64 F (Genoa) with SMT, base frequency 3.95 GHz, peak 4.3 GHz. o Memory: 16 GiB to 160 GiB. o Storage: NVMe-based ephemeral local storage supported. VM Sizes: o Ranges from Standard_NV4ads_V710_v5 (4 vCPUs, 16 GiB RAM, 1/6 GPU) to Standard_NV28adms_V710_v5 (28 vCPUs, 160 GiB RAM, full GPU). Supported Features: o Premium storage, accelerated networking, ephemeral OS disk. o Both Windows and Linux VMs supported. o No additional GPU licensing is required. AMD Radeon™ PRO GPUs offer: o Optimized OpenGL professional driver stack o Stable interactive performance vs large assemblies Business Scenario Enabled by NX + Cloud GPU Engineering Anywhere Distributed teams can securely work on the same assemblies from any geographic region. Supplier Ecosystem Collaboration Tier-1/2 manufacturers and engineering partners can access controlled models without local high-end workstations. Secure IP Protection Data stays in Azure — files never leave the controlled workspace. Faster Engineering Cycles Visualization + simulation accelerate design reviews, decision making, and manufacturability evaluations. Scalable Cost Model Pay for compute only when needed — ideal for burst design cycles and testing workloads. Architecture Overview – Siemens NX on Azure NVads_v710 Key Architecture Elements Create Azure Virtual Machine- NVads_v710_24 Install Azure AMD V710 GPU drivers Deploy Azure File-based storage Hosting assemblies, metadata, drawing packages, PMI, simulation data. Configure Vnet with Accelerated Networking Install NX licenses and software. Install NXCP & ATS Test suites on the Virtual Machine Qualitative Benchmark on Azure NVads_v710_24 Siemens has approved the following qualitative test results. The certification matrix update is currently in progress. Technical variant: Complex assemblies with thousands of components maintained smooth rotation, zooming, and selection, even under concurrent session load. NXCP and ATS test results on NVads_v710_24 Non-Interactive test results: Note: Execution Time (seconds) ATS Non‑Interactive Test Results validate the correctness and stability of Siemens NX graphical rendering by comparing generated images against approved reference outputs. The minimal or zero pixel differences confirm deterministic and visually consistent rendering, indicating a stable GPU driver and visualization pipeline. The reported test execution times (in seconds) represent the duration required to complete each automated graphics validation scenario, demonstrating predictable and repeatable processing performance under non‑interactive conditions. Interactive test results on Azure NVads_v710_24: Note: Execution Time (seconds) ATS Interactive Test Results evaluate Siemens NX graphics behavior during real‑time user interactions such as rotation, zoom, pan, sectioning, and view manipulation. The results demonstrate stable and consistent rendering during interactive workflows, confirming that the GPU driver and visualization stack reliably support user‑driven NX operations. The measured execution times (in seconds) reflect the responsiveness of each interactive graphics operation, indicating predictable behavior under live, user‑controlled conditions rather than peak performance tuning. NX CAD functions Automatic Tests Interactive Tests Grace1 Basic Tests GrPlayer_xp64.exe <FILE> Basic_Features.tgl Passed! Passed! GrPlayer_xp64.exe <FILE> Fog_Measurement_Clipping.tgl Passed! Passed! GrPlayer_xp64.exe <FILE> lighting.tgl Passed! Passed! GrPlayer_xp64.exe <FILE> Shadow_Bump_Environment.tgl Passed! Passed! GrPlayer_xp64.exe <FILE> Texture_Map.tgl Passed! Passed! Grace2 Graphics Tests GrPlayer_64.exe <FILE> GrACETrace.tgl Passed! Passed! Grace2 Graphics Tests GrPlayer_64.exe <FILE> GrACETrace.tgl Passed! Passed! NXCP Test Scenarios Automatic Tests NXCP Gdat Tests gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_1.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_2.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_4.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_5.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_6.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_7.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_8.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_9.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_10.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_11.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_12.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_13.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_14.cgi Passed! gdat_leg_xp64.exe -infile <FILE> leg_gfx_cert_15.cgi Passed! Benefits Azure NVads_v710 (AMD GPU Platform for NX Workstation-class AMD Radeon PRO graphics drivers baked into Azure Ensures ISV-validated driver pipeline. Excellent performance for CAD workloads Makes GPU-accelerated NX accessible to wider user bases. Remote engineering enablement Critical for companies who now operate global design teams. Elastic scale Spin up GPU when development peaks; scale down when idle. Conclusion: Siemens NX on Azure NVads_v710 powered by AMD GPUs enables enterprise-class CAD/CAM/CAE experiences in the cloud. NX benefits directly from workstation-grade OpenGL optimization, shading stability, and Ray Traced Studio acceleration, allowing engineers to interact smoothly with large assemblies, run visualization workloads, and perform design reviews without local hardware dependencies. Right‑sized GPU delivers workstation‑class experience at lower cost The family enables fractional GPU allocation (down to 1/6 of a Radeon™ Pro V710), allowing Siemens NX deployments to be right‑sized per user role. This avoids over‑provisioning full GPUs while still delivering ISV‑grade OpenGL and visualization stability, resulting in a lower per‑engineer cost compared to fixed full‑GPU cloud or on‑prem workstations Elastic scale improves cost efficiency for burst engineering workloads NVads_V710_v5 instances support on demand scaling and ephemeral NVMe storage, allowing NX environments to scale up for design reviews, supplier collaboration, or peak integration cycles and scale down when idle. This consumption model provides a cost advantage over fixed on prem workstations that remain underutilized outside peak engineering periods NX visualization pipelines benefit from balanced CPU–GPU architecture The combination of high‑frequency AMD EPYC™ Genoa CPUs (up to 4.3 GHz) and Radeon™ Pro V710 GPUs addresses Siemens NX’s mixed CPU–GPU workload profile, where scene graph processing, tessellation, and OpenGL submission are CPU‑sensitive. This balance reduces idle GPU cycles, improving effective utilization and overall cost efficiency when compared with GPU‑heavy but CPU‑constrained configurations The result is a scalable, secure, and cost-efficient engineering platform that supports distributed innovation, supplier collaboration, and digital product development workflows — all backed by the Rendering and interaction consistency of AMD GPU virtualization on Azure.
Announcing Azure CycleCloud Workspace for Slurm: Version 2025.12.01 Release
The Azure CycleCloud Workspace for Slurm 2025.12.01 release introduces major upgrades that strengthen performance, monitoring, authentication, and platform flexibility for HPC environments. This update integrates Prometheus self‑agent monitoring and Azure Managed Grafana, giving teams real‑time visibility into node metrics, Slurm jobs, and cluster health through ready‑to‑use dashboards. The release also adds Entra ID Single Sign‑On (SSO) to streamline secure access across CycleCloud and Open OnDemand. With centralized identity management and support for MFA, organizations can simplify user onboarding while improving security. Additionally, the update expands platform support with ARM64 compute nodes and compatibility for Ubuntu 24.04 and AlmaLinux 9, enabling more flexible and efficient HPC cluster deployments. Overall, this version focuses on improved observability, stronger security, and broader infrastructure options for technical and scientific HPC teams.Monitoring HPC & AI Workloads on Azure H/N VMs Using Telegraf and Azure Monitor (GPU & InfiniBand)
As HPC & AI workloads continue to scale in complexity and performance demands, ensuring visibility into the underlying infrastructure becomes critical. This guide presents an essential monitoring solution for AI infrastructure deployed on Azure RDMA-enabled virtual machines (VMs), focusing on NVIDIA GPUs and Mellanox InfiniBand devices. By leveraging the Telegraf agent and Azure Monitor, this setup enables real-time collection and visualization of key hardware metrics, including GPU utilization, GPU memory usage, InfiniBand port errors, and link flaps. It provides operational insights vital for debugging, performance tuning, and capacity planning in high-performance AI environments. In this blog, we'll walk through the process of configuring Telegraf to collect and send GPU and InfiniBand monitoring metrics to Azure Monitor. This end-to-end guide covers all the essential steps to enable robust monitoring for NVIDIA GPUs and Mellanox InfiniBand devices, empowering you to track, analyze, and optimize performance across your HPC & AI infrastructure on Azure. DISCLAIMER: This is an unofficial configuration guide and is not supported by Microsoft. Please use it at your own discretion. The setup is provided "as-is" without any warranties, guarantees, or official support. While Azure Monitor offers robust monitoring capabilities for CPU, memory, storage, and networking, it does not natively support GPU or InfiniBand metrics for Azure H- or N-series VMs. To monitor GPU and InfiniBand performance, additional configuration using third-party tools—such as Telegraf—is required. As of the time of writing, Azure Monitor does not include built-in support for these metrics without external integrations. 🔔 Update: Supported Monitoring Option Now Available Update (December 2025): At the time this guide was written, monitoring InfiniBand (IB) and GPU metrics on Azure H-series and N-series VMs required a largely unofficial approach using Telegraf and Azure Monitor. Microsoft has since introduced a supported solution: Azure Managed Prometheus on VM / VM Scale Sets (VMSS), currently available in private preview. This new capability provides a native, managed Prometheus experience for collecting infrastructure and accelerator metrics directly from VMs and VMSS. It significantly simplifies deployment, lifecycle management, and long-term support compared to custom Telegraf-based setups. For new deployments, customers are encouraged to evaluate Azure Managed Prometheus on VM / VMSS as the preferred and supported approach for HPC and AI workload monitoring. Official announcement: Private Preview: Azure Managed Prometheus on VM / VMSS Step 1: Making changes in Azure for sending GPU and IB metrics from Telegraf agents to Azure monitor from VM or VMSS. Register the microsoft.insights resource provider in your Azure subscription. Refer: Resource providers and resource types - Azure Resource Manager | Microsoft Learn Step 2: Enable Managed Service Identities to authenticate an Azure VM or Azure VMSS. In the example we are using Managed Identity for authentication. You can also use User Managed Identities or Service Principle to authenticate the VM. Refer: telegraf/plugins/outputs/azure_monitor at release-1.15 · influxdata/telegraf (github.com) Step 3: Set Up the Telegraf Agent Inside the VM or VMSS to Send Data to Azure Monitor In this example, I'll use an Azure Standard_ND96asr_v4 VM with the Ubuntu-HPC 2204 image to configure the environment for VMSS. The Ubuntu-HPC 2204 image comes with pre-installed NVIDIA GPU drivers, CUDA, and InfiniBand drivers. If you opt for a different image, ensure that you manually install the necessary GPU drivers, CUDA toolkit, and InfiniBand driver. Next, download and run the gpu-ib-mon_setup.sh script to install the Telegraf agent on Ubuntu 22.04. This script will also configure the NVIDIA SMI input plugin and InfiniBand Input Plugin, along with setting up the Telegraf configuration to send data to Azure Monitor. Note: The gpu-ib-mon_setup.sh script is currently supported and tested only on Ubuntu 22.04. Please read the InfiniBand counter collected by Telegraf - https://enterprise-support.nvidia.com/s/article/understanding-mlx5-linux-counters-and-status-parameters Run the following commands: wget https://raw.githubusercontent.com/vinil-v/gpu-ib-monitoring/refs/heads/main/scripts/gpu-ib-mon_setup.sh -O gpu-ib-mon_setup.sh chmod +x gpu-ib-mon_setup.sh ./gpu-ib-mon_setup.sh Test the Telegraf configuration by executing the following command: sudo telegraf --config /etc/telegraf/telegraf.conf --test Step 4: Creating Dashboards in Azure Monitor to Check NVIDIA GPU and InfiniBand Usage Telegraf includes an output plugin specifically designed for Azure Monitor, allowing custom metrics to be sent directly to the platform. Since Azure Monitor supports a metric resolution of one minute, the Telegraf output plugin aggregates metrics into one-minute intervals and sends them to Azure Monitor at each flush cycle. Metrics from each Telegraf input plugin are stored in a separate Azure Monitor namespace, typically prefixed with Telegraf/ for easy identification. To visualize NVIDIA GPU usage, go to the Metrics section in the Azure portal: Set the scope to your VM. Choose the Metric Namespace as Telegraf/nvidia-smi. From there, you can select and display various GPU metrics such as utilization, memory usage, temperature, and more. In example we are using GPU memory_used metrics. Use filters and splits to analyze data across multiple GPUs or over time. To monitor InfiniBand performance, repeat the same process: In the Metrics section, set the scope to your VM. Select the Metric Namespace as Telegraf/infiniband. You can visualize metrics such as port status, data transmitted/received, and error counters. In this example, we are using a Link Flap Metrics to check the InfiniBand link flaps. Use filters to break down the data by port or metric type for deeper insights. Link_downed Metric Note: The link_downed metric with Aggregation: Count is returning incorrect values. We can use Max, Min values. Port_rcv_data metrics Creating custom dashboards in Azure Monitor with both Telegraf/nvidia-smi and Telegraf/infiniband namespaces allows for unified visibility into GPU and InfiniBand. Testing InfiniBand and GPU Usage If you're testing GPU metrics and need a reliable way to simulate multi-GPU workloads—especially over InfiniBand—here’s a straightforward solution using the NCCL benchmark suite. This method is ideal for verifying GPU and network monitoring setups. NCCL Benchmark and OpenMPI is part of the Ubuntu HPC 22.04 image. Update the variable according to your environment. Update the hostfile with the hostname. module load mpi/hpcx-v2.13.1 export CUDA_VISIBLE_DEVICES=2,3,0,1,6,7,4,5 mpirun -np 16 --map-by ppr:8:node -hostfile hostfile \ -mca coll_hcoll_enable 0 --bind-to numa \ -x NCCL_IB_PCI_RELAXED_ORDERING=1 \ -x LD_LIBRARY_PATH=/usr/local/nccl-rdma-sharp-plugins/lib:$LD_LIBRARY_PATH \ -x CUDA_DEVICE_ORDER=PCI_BUS_ID \ -x NCCL_SOCKET_IFNAME=eth0 \ -x NCCL_TOPO_FILE=/opt/microsoft/ndv4-topo.xml \ -x NCCL_DEBUG=WARN \ /opt/nccl-tests/build/all_reduce_perf -b 8 -e 8G -f 2 -g 1 -c 1 Alternate: GPU Load Simulation Using TensorFlow If you're looking for a more application-like load (e.g., distributed training), I’ve prepared a script that sets up a multi-GPU TensorFlow training environment using Anaconda. This is a great way to simulate real-world GPU workloads and validate your monitoring pipelines. To get started, run the following: wget -q https://raw.githubusercontent.com/vinil-v/gpu-monitoring/refs/heads/main/scripts/gpu_test_program.sh -O gpu_test_program.sh chmod +x gpu_test_program.sh ./gpu_test_program.sh With either method NCCL benchmarks or TensorFlow training you’ll be able to simulate realistic GPU usage and validate your GPU and InfiniBand monitoring setup with confidence. Happy testing! References: Ubuntu HPC on Azure ND A100 v4-series GPU VM Sizes Telegraf Azure Monitor Output Plugin (v1.15) Telegraf NVIDIA SMI Input Plugin (v1.15) Telegraf InfiniBand Input Plugin Documentation
