SQL Server installation issues

SivertSolem aolawoyin

Based on the text in your ERRORLOG, this is the more likely culprit:
https://learn.microsoft.com/en-us/troubleshoot/sql/database-engine/database-file-operations/troubleshoot-os-4kb-disk-sector-size#:~:text=for%20potential%20causes.-,Scenario%20%232%3A,-You%20install%20any

You're attempting to install SQL Server on a drive with a "physical sector size" larger than 4k on a Windows 11 machine, and most likely need to enable emulation of 4k "physical sector size".

You can verify this using the following in command or powershell (administrator)

fsutil fsinfo sectorinfo C

  Compare the values PhysicalBytesPerSectorForAtomicity and PhysicalBytesPerSectorForPerformance, and if either of them are larger than 4096, your symptoms would be likely to show up.

Using powershell as administrator, you can add a registry key value pair.

New-ItemProperty -Path "HKLM:\SYSTEM\CurrentControlSet\Services\stornvme\Parameters\Device" -Name "ForcedPhysicalSectorSizeInBytes" -PropertyType MultiString -Force -Value "* 4095"

After a reboot, you should be able to start SQL Server.

Alternatively, you can start SQL Server using traceflag 1800.

This article describes how to add trace flags as startup parameters to SQL Server.
https://www.sqlshack.com/microsoft-sql-server-trace-flags-and-usage-details/#:~:text=Adding%20a%20trace%20flag%20into%20the%20Microsoft%20SQL%20Server%20startup%20parameters

Balmukund-Lakhani .Thanks for the reply. This is the error log:

Balmukund-Lakhani- I have similar issue installing . here is the log , plz advise

Overall summary:
Final result: Failed: see details below
Exit code (Decimal): -2061893606
Start time: 2024-03-14 09:57:48
End time: 2024-03-14 10:05:08
Requested action: Install

Setup completed with required actions for features.
Troubleshooting information for those features:
Next step for SQLEngine: Use the following information to resolve the error, uninstall this feature, and then run the setup process again.
Next step for Replication: Use the following information to resolve the error, uninstall this feature, and then run the setup process again.

Machine Properties:
Machine name: BOOK-KBGTPVNPIU
Machine processor count: 16
OS version: Microsoft Windows 11 Home (10.0.22631)
OS service pack:
OS region: United States
OS language: English (United Kingdom)
OS architecture: x64
Process architecture: 64 Bit
OS clustered: No

Product features discovered:
Product Instance Instance ID Feature Language Edition Version Clustered Configured

Package properties:
Description: Microsoft SQL Server 2022
ProductName: SQL Server 2022
Type: RTM
Version: 16
SPLevel: 0
Installation location: C:\SQL2022\Developer_ENU\x64\setup\
Installation edition: Express

Product Update Status:
None discovered.

Notice: Please read Microsoft SQL Server Software License Terms at aka.ms/useterms.

User Input Settings:
ACTION: Install
ADDCURRENTUSERASSQLADMIN: false
AGTSVCACCOUNT: NT AUTHORITY\NETWORK SERVICE
AGTSVCPASSWORD: *****
AGTSVCSTARTUPTYPE: Disabled
ASBACKUPDIR: Backup
ASCOLLATION: Latin1_General_CI_AS
ASCONFIGDIR: Config
ASDATADIR: Data
ASLOGDIR: Log
ASPROVIDERMSOLAP: 1
ASSERVERMODE: TABULAR
ASSVCACCOUNT: <empty>
ASSVCPASSWORD: <empty>
ASSVCSTARTUPTYPE: Automatic
ASSYSADMINACCOUNTS: <empty>
ASTELSVCACCT: <empty>
ASTELSVCPASSWORD: <empty>
ASTELSVCSTARTUPTYPE: 0
ASTEMPDIR: Temp
AZUREARCPROXYSERVER:
AZUREBILLEDEDITION:
AZUREREGION:
AZURERESOURCEGROUP:
AZURESERVICEPRINCIPAL:
AZURESERVICEPRINCIPALSECRET: *****
AZURESUBSCRIPTIONID:
AZURETENANTID:
BROWSERSVCSTARTUPTYPE: Disabled
CONFIGURATIONFILE: C:\Program Files\Microsoft SQL Server\160\Setup Bootstrap\Log\20240314_095748\ConfigurationFile.ini
ENABLERANU: true
ENU: true
EXTSVCACCOUNT: <empty>
EXTSVCPASSWORD: <empty>
FEATURES: SQLENGINE, REPLICATION
FILESTREAMLEVEL: 0
FILESTREAMSHARENAME: <empty>
FTSVCACCOUNT: <empty>
FTSVCPASSWORD: <empty>
HELP: false
IACCEPTSQLSERVERLICENSETERMS: true
IACKNOWLEDGEENTCALLIMITS: false
INDICATEPROGRESS: false
INSTALLSHAREDDIR: C:\Program Files\Microsoft SQL Server\
INSTALLSHAREDWOWDIR: C:\Program Files (x86)\Microsoft SQL Server\
INSTALLSQLDATADIR: <empty>
INSTANCEDIR: C:\Program Files\Microsoft SQL Server\
INSTANCEID: MYSQL
INSTANCENAME: MYSQL
ISMASTERSVCACCOUNT: NT AUTHORITY\Network Service
ISMASTERSVCPASSWORD: <empty>
ISMASTERSVCPORT: 8391
ISMASTERSVCSSLCERTCN: <empty>
ISMASTERSVCSTARTUPTYPE: Automatic
ISMASTERSVCTHUMBPRINT: <empty>
ISSVCACCOUNT: NT AUTHORITY\Network Service
ISSVCPASSWORD: <empty>
ISSVCSTARTUPTYPE: Automatic
ISTELSVCACCT: <empty>
ISTELSVCPASSWORD: <empty>
ISTELSVCSTARTUPTYPE: 0
ISWORKERSVCACCOUNT: NT AUTHORITY\Network Service
ISWORKERSVCCERT: <empty>
ISWORKERSVCMASTER: <empty>
ISWORKERSVCPASSWORD: <empty>
ISWORKERSVCSTARTUPTYPE: Automatic
NPENABLED: 0
PBDMSSVCACCOUNT: <empty>
PBDMSSVCPASSWORD: <empty>
PBDMSSVCSTARTUPTYPE: 0
PBENGSVCACCOUNT: <empty>
PBENGSVCPASSWORD: <empty>
PBENGSVCSTARTUPTYPE: 0
PBPORTRANGE: <empty>
PID: *****
PRODUCTCOVEREDBYSA: false
QUIET: false
QUIETSIMPLE: false
ROLE:
SAPWD: *****
SECURITYMODE: SQL
SQLBACKUPDIR: <empty>
SQLCOLLATION: Latin1_General_CI_AS
SQLMAXDOP: 0
SQLMAXMEMORY: 2147483647
SQLMINMEMORY: 0
SQLSVCACCOUNT: NT Service\MSSQL$MYSQL
SQLSVCINSTANTFILEINIT: true
SQLSVCPASSWORD: <empty>
SQLSVCSTARTUPTYPE: Automatic
SQLSYSADMINACCOUNTS: BOOK-KBGTPVNPIU\dans_
SQLTELSVCACCT: NT Service\SQLTELEMETRY$MYSQL
SQLTELSVCPASSWORD: <empty>
SQLTELSVCSTARTUPTYPE: Automatic
SQLTEMPDBDIR: <empty>
SQLTEMPDBFILECOUNT: 1
SQLTEMPDBFILEGROWTH: 64
SQLTEMPDBFILESIZE: 8
SQLTEMPDBLOGDIR: <empty>
SQLTEMPDBLOGFILEGROWTH: 64
SQLTEMPDBLOGFILESIZE: 8
SQLUSERDBDIR: <empty>
SQLUSERDBLOGDIR: <empty>
SUPPRESSPAIDEDITIONNOTICE: false
SUPPRESSPRIVACYSTATEMENTNOTICE: false
TCPENABLED: 0
UIMODE: Normal
UpdateEnabled: true
UpdateSource: MU
USEMICROSOFTUPDATE: false
USESQLRECOMMENDEDMEMORYLIMITS: false

Configuration file: C:\Program Files\Microsoft SQL Server\160\Setup Bootstrap\Log\20240314_095748\ConfigurationFile.ini

Detailed results:
Feature: Database Engine Services
Status: Failed
Reason for failure: An error occurred during the setup process of the feature.
Next Step: Use the following information to resolve the error, uninstall this feature, and then run the setup process again.
Component name: SQL Server Database Engine Services Instance Features
Component error code: 0x851A001A
Error description: Wait on the Database Engine recovery handle failed. Check the SQL Server error log for potential causes.
Error help link: https://go.microsoft.com/fwlink?LinkId=20476&ProdName=Microsoft+SQL+Server&Evtsrc=setup.rll&EvtID=50000&ProdVer=16.0.1000.6&EvtType=0xD15B4EB2%400x4BDAF9BA%401306%4026&EvtType=0xD15B4EB2%400x4BDAF9BA%401306%4026

Feature: SQL Server Replication
Status: Failed
Reason for failure: An error occurred for a dependency of the feature causing the setup process for the feature to fail.
Next Step: Use the following information to resolve the error, uninstall this feature, and then run the setup process again.
Component name: SQL Server Database Engine Services Instance Features
Component error code: 0x851A001A
Error description: Wait on the Database Engine recovery handle failed. Check the SQL Server error log for potential causes.
Error help link: https://go.microsoft.com/fwlink?LinkId=20476&ProdName=Microsoft+SQL+Server&Evtsrc=setup.rll&EvtID=50000&ProdVer=16.0.1000.6&EvtType=0xD15B4EB2%400x4BDAF9BA%401306%4026&EvtType=0xD15B4EB2%400x4BDAF9BA%401306%4026

Feature: SQL Browser
Status: Passed

Feature: SQL Writer
Status: Passed

Feature: Setup Support Files
Status: Passed

Rules with failures or warnings:

Global rules:
Warning IsFirewallEnabled The Windows Firewall is enabled. Make sure the appropriate ports are open to enable remote access. See the rules documentation at https://go.microsoft.com/fwlink/?linkid=2162127 for information about ports to open for each feature.

Rules report file: C:\Program Files\Microsoft SQL Server\160\Setup Bootstrap\Log\20240314_095748\SystemConfigurationCheck_Report.htm
