Forum Discussion
Deployment Framework for BizTalk 2020
I installed Biztalk deployment framework 5.8 on dev machine.
Does anybody installed the BTDF extension for VS 2019 ?
I am not able to find the installable on the vistual studio market place .
Any help is appreciated .
15 Replies
Hallo zusammen,
wir haben die BTDF Extensions für VS 2019 migrieren können. Wer dies auch machen möchte, hier eine kurze Einleitung, wie das für uns funktioniert hat.
https://datapassion.de/index.php/dpnews/btdf-extentions-for-vs-2019-biztalk-deployment-framework-2020-visual-studio-2019-extentions
Bitte beachtet, dass dies nur ein Workaround ist, bis der Autor eine offizielle Version uns allen zur Verfügung stellt.
Bei Fragen meldet Euch bei uns - DATA Passion GmbH
Hi all,
we have a solution how to run BTDF 2020 Extensions under VS 2019:
https://datapassion.de/index.php/dpnews/btdf-extentions-for-vs-2019-biztalk-deployment-framework-2020-visual-studio-2019-extentions
Please consider this is just a workaround until we all have the official version.
I hope we can help.
Let's make integration smart today
- I am building the BTDF.ToolsForVisualStudio and getting the following error;
Error: The "ResolveComReference" task returned false but did not log an error.
project name: DeploymentFrameworkForBizTalkAddin
I really appreciate any help you can provide. Attempting to install Microsoft.VisualStudio.Shell.15.0 latest version will not work because one of the dependent packages is built just for .net core. To workaround this, install version 16.0.28729.
Hi DATA_Passion_GmbH ,
I tried installing the btdf extension for VS 2019 but facing the following issue while building the solution. Could you pls help me with this.
Error CS0006 Metadata file 'D:\Softwares\ToolsForVisualStudio-master\ToolsForVisualStudio-master\src\AddIn.ProjectWizard\bin\Debug\DeploymentFxForBizTalkAddin.ProjectWizard.dll' could not be found DeploymentFrameworkForBizTalkAddin.ProjectWizard.Test D:\Softwares\ToolsForVisualStudio-master\ToolsForVisualStudio-master\src\AddIn.ProjectWizard.Test\CSC 1 ActiveThanks in advance!
Regards,
Dileep N
AmitaBarge1gmailcomThe Visual Studio 2019 extension is not yet available, and I do not have a release date to share. v5.8 of the Framework itself is available in stable beta form for BizTalk 2020.
You can follow the VS extension https://github.com/BTDF/ToolsForVisualStudio.
Thanks,
Thomas Abraham
tfabraham - I have installed the BTDF V5.8 to be used for BizTalk 2020 upgrade/migration project.
Although the build path had to be changed to the VS2019 current\bin folder inorder to build, I am facing an issue with the deployment with the error as below.
BizTalkDeploymentFramework.targets(1769,3): error MSB4067: The element <ItemDefinitionGroup> beneath element <Project> is unrecognized.
Upon further checking the files, it has below code; which wasnt in the v5.7. What is the use of this below code and how to resolve the error MSB4067?
<ItemDefinitionGroup>
<IISAppPool>
<DotNetFrameworkVersion>v4.0</DotNetFrameworkVersion>
<PipelineMode>Integrated</PipelineMode>
<Enable32Bit>False</Enable32Bit>
<IdentityType>ApplicationPoolIdentity</IdentityType>
<DeployAction>$(IISAppPoolDefaultDeployAction)</DeployAction>
<UndeployAction>$(IISAppPoolDefaultUndeployAction)</UndeployAction>
</IISAppPool>
</ItemDefinitionGroup><ItemDefinitionGroup>
<IISApp>
<SiteName>Default Web Site</SiteName>
<DeployAction>CreateOrUpdate</DeployAction>
<UndeployAction>Delete</UndeployAction>
</IISApp>
</ItemDefinitionGroup>- glav27 - resolved the above issue by using the packaged framework assemblies included in "MyBTProject\1.0\Deployment\Framework" with the 5.7 versions (e.g.: BizTalkDeploymentFramework.Tasks.dll). Something when packaging from VS2019 has those assemblies on a different build version, reverting them resolved the problem for us. Would be great to have these work by default for BT2020 and VS2019 🙂
- Anxious for release. Thank you for link.
