4K Display issue with BizTalk (in VS and BTS Administration Console)

Does it help if you set scaling option in Windows display settings to 100% (assuming you may have 150% or 200% instead)?

What is the result of this powershell script? (getting details about resolution, scaling, monitors and version of VS 2019)

-------

Add-Type -AssemblyName System.Windows.Forms

$screen_cnt = [System.Windows.Forms.Screen]::AllScreens.Count

$col_screens = [system.windows.forms.screen]::AllScreens

$vs2019file = "C:\Program Files (x86)\Microsoft Visual Studio\2019\Enterprise\Common7\IDE\devenv.exe"



$info_screens = ($col_screens | ForEach-Object {

if ("$($_.Primary)" -eq "True") {$monitor_type = "Primary Monitor "} else {$monitor_type = "Secondary Monitor "}

if ("$($_.Bounds.Width)" -gt "$($_.Bounds.Height)") {$monitor_orientation = "Landscape"} else {$monitor_orientation = "Portrait"}

$monitor_type + "(Bounds) " + "$($_.Bounds)"

$monitor_type + "(Primary) " + "$($_.Primary)"

$monitor_type + "(Device Name) " + "$($_.DeviceName)"

$monitor_type + "(Bounds Width x Bounds Height) " + "$($_.Bounds.Width) x $($_.Bounds.Height) ($monitor_orientation)"

$monitor_type + "(Bits Per Pixel) " + "$($_.BitsPerPixel)"

$monitor_type + "(Working Area) " + "$($_.WorkingArea)"

}

)

If ((Test-Path $vs2019file) -eq $True) {

$devenvversion = (Get-ChildItem -Path $vs2019file).VersionInfo.ProductVersion

}

else {

$devenvversion = "*Not existing*"

}

$DPISetting = (Get-ItemProperty 'HKCU:\Control Panel\Desktop\WindowMetrics' -Name AppliedDPI).AppliedDPI

Write-Host "VS DevEnv.exe version : $devenvversion"

Write-Host "DPI setting (96=100%) : $DPISetting"

Write-Host "TOTAL SCREEN COUNT: $screen_cnt"

$info_screens



----------
